- Page 1 -- SGP-110 -- (NOVA TEAM™ SQUARE) Installation Instructions Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com Rev-B Page 1 of 9...
- Page 2 JAYPRO SPORTS SGP-110, NOVA TEAM™ SQUARE ITEM IMAGE (Actual image may vary) DESCRIPTION FRONT CROSSBAR, 2" x 4" x 280" LONG SGP-10 RIGHT & LEFT CORNER SGP-110 RIGHT & LEFT UPRIGHT SGP-110 BACKSTAY 1.90" BACKSTAY CONNECTOR, x 96-5/8" L 1.90" REAR CROSSBAR, x 288" L 1.90"...
- Page 3 JAYPRO SPORTS SGP-110, NOVA TEAM™ SQUARE ITEM IMAGE (Actual image may vary) DESCRIPTION 3/8”-16 x 3/4” BUTTON HEX SCREW, SS 3/8"-16 x 2 3/4" HEX HEAD CAP SCREW, 3/8"-16 THIN NYLON LOCK NUT NTE, ZP 3/8" SAE FLAT WASHER, ZP 3/8"...
-
Page 4: Tools Required
2) USE OF THIS EQUIPMENT OTHER THAN INTENDED MAY BE HAZARDOUS. 3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS. ASSEMBLY INSTRUCTIONS TOOLS REQUIRED: (1) 9/16” Socket Wrench and Box Wrench... - Page 5 Front Goal Face Assembly: 1. Lay goal components face down on the grass or a protective surface. 2. Slide crossbar into uprights and assemble hardware hand tight. Note the orientation of the uprights, cap end on tube is the bottom. 3/8”-16 x 3/4”...
- Page 6 Rear Backstay Assembly: 1. Insert the backstays into the swaged end of the pipe before placing into the hubs. Repeat for the other half of the goal. 2. Now insert the completed backstays into the hubs and hand tighten the hardware. 3.
- Page 7 Place labels according to the diagrams below. Always inspect goals before each use to ensure that all labels are in place and legible. Contact your dealer or Jaypro Sports for replacement labels. Label Placement Instructions:...
-
Page 8: Important Notice
Final Adjustments: • Check to make sure the soccer goal frame is properly aligned and square. Securely tighten all hex head hardware. • With goal fully assembled, attach the net using the Easy Track net clip attachment system: • Use a step ladder to attach the net to the crossbar if necessary. Once completed, move the goal into the final playing position. - Page 9 Anchoring Systems: IMPORTANT – PORTABLE SOCCER GOALS SHOULD BE ANCHORED AT ALL TIMES. There are three categories of anchors suitable for securing soccer goals. Semi-Permanent In-Ground Anchors: SGA-60 Semi-permanent in-ground anchors are the most secure type of anchor, as they are not dependent on soil conditions or subject to improper placement or dislodging.
