FireAngel Multisensor Plus Operating Instructions Manual page 26

Version
Maximum service life
Power supply
Compliance
Operating temperature
Operating humidity
Radio frequency
Radio independently tested according to EN 301 489-1; EN 301 489-3; EN 300 220-2
Maximum RF power
Laser (for environment monitoring)
Dimensions (D x H):
-
26
Multisensor Plus
10 Jahre (+ 6 months)
Ì Permanently installed non-replaceable long-life lithium battery
Ì Battery life: 10 years + 1 year reserve
EN 14604 2005 + AC 2008 (CE);
DIN 14676-1 2018 according to
EN 50291-1 2018; BS 5446-2 2003
-10 bis 40 °C
0 % bis 90 % relative humidity
869,775 MHz
869,925 MHz
868,95 MHz
14 dBm (25 mW)
Class 1 according to EN 60825-1:2022-07
135 mm x 72 mm (including mounting plate)
Multisensor Plus Kitchen
EN 50291-1 2018;
BS 5446-2 2003
MULTISENSOR PLUS
