3000 Series Door Closer
Models PR3301, PR3311, PR3501, PR3511, 3321(T), 3521(T)
Parallel Rigid or Holder/Stop Arm, Non-Hold Open or Hold Open
Installation Instructions
Closer mounts on opposite to hinge (push) side of door. PR3301 Parallel Rigid Non-Hold Open arm illustrated. Slim Line Cover shown.
Right Hand Door - RH
Left Hand Reverse - LHR
Closer mounts on opposite to hinge (push) side of door. 3521 Holder/Stop arm illustrated. Full Cover shown.
Right Hand Door - RH
Left Hand Reverse - LHR
Closer mounts on opposite to hinge (push) side of door. 3521T Holder/Stop arm with Thumbturn Hold Open illustrated.
Right Hand Door - RH
Left Hand Reverse - LHR
NOTES:
‒ For special applications, a separate door and frame preparation template is included with these instructions. In those cases, use
this instruction sheet for installation sequence and closer adjustments only.
‒ "T" indicates Thumbturn actuated Hold Open, units are handed.
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening, and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific
situation. When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated open-
ing, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with
all applicable codes and ratings.
855-557-5078 x 2 • www.accentra-assaabloy.com
Copyright © 2004, 2010, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
80-9303-2209-010 Rev 3 05/24
Standard Frame Installation
Refer to pages 3 and 4
Narrow Frame Installation
890 and 891 accessories required for this application (supplied separately).
Refer to pages 3 and 4
Flush Partition Installation
Full Cover shown. 293L accessory required for this application (supplied separately).
Refer to pages 3 and 4
Left Hand Door - LH
Right Hand Reverse - RHR
Left Hand Door - LH
Right Hand Reverse - RHR
Left Hand Door - LH
Right Hand Reverse - RHR
