Assa Abloy ACCENTRA 4400 Series Installation Instructions Manual

4400 Series Door Closer
Models 4480, TJ4480, and PA4480
Low Profile, Regular Arm, Top Jamb, or Parallel Arm, Non-Hold Open
Installation Instructions
Left Hand Door - LH
Right Hand Reverse - RHR
Right Hand Door - RH
Left Hand Reverse - LHR
Right Hand Door - RH
Left Hand Reverse - LHR
NOTES:
‒ For Special Applications a separate door and frame preparation template is packed with these instructions.
Use this instruction sheet for installation sequence and closer adjustments only.
‒ This document applies to models with or without the "DL" (Delayed Action) or "M" (Metal Cover) suffix.
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening, and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific
situation. When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated open-
ing, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with
all applicable codes and ratings.
855-557-5078 x 2 • www.accentra-assaabloy.com
Copyright © 1991, 2012, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
80-9344-1203-010 Rev 3 05/24
Closer mounts on hinge (pull) side of the door. Closer cover not shown.
Closer mounts on frame face on opposite to hinge (push) side of the door. Closer cover not shown.
Closer mounts on opposite to hinge (push) side of the door. Closesr cover not shown.
Regular Arm
See page 3.
Top Jamb Mount
See page 4.
Parallel Arm
See page 5.
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
Left Hand Door - LH
Right Hand Reverse - RHR
