Assa Abloy ACCENTRA 3000 Series Installation Instructions

3000 Series
Models 3381 and 3581
Low Profile Arm, Non-Hold Open
Installation Instructions
Left Hand Door - LH
Right Hand Reverse - RHR
Right Hand Door - RH
Left Hand Reverse - LHR
NOTES:
‒ For Special Applications a separate door and frame preparation template is packed with these instructions. Use this instruction sheet for installation
sequence and closer adjustments only.
‒ "DL" Suffix - Delayed Action closing is an optional feature.
Closer Components
Backcheck Valve
Latch Valve
Closer Body
Sweep Valve
Regular Arm/Top
289A Parallel Arm
Jamb Shoe
Bracket
Forearm Screw
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening, and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific
situation. When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated open-
ing, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with
all applicable codes and ratings.
855-557-5078 x 2 • www.accentra-assaabloy.com
Copyright © 2004, 2009, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
80-9303-2210-010 Rev 3 05/24
Regular Arm Installation
Closer mounts on hinge (pull) side of door
Parallel Arm Installation
Closer mounts on opposite to hinge (push) side of door
Spring Adjustment
Shaft
Cover
Insert
Power
Size
Standard Full Cover
Main Arm
Standoff
Forearm
Connecting Rod
Closer Arm
Refer to page 2
Refer to page 3
Insert Cutouts
Optional Narrow Plastic Cover
(3200P)
(3400P)
Standoff
Insert
Cover
Cutouts
Insert
Optional Architectural Plastic Full Cover
(3400A)
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
Cover Screw
Cover
Clips
Pinion Cap
(1639)
Cover
Optional Metal Cover
Screw (3400M)
Cover Screw
Standoffs
Screw Pack
Cover Screw
Optional Architectural Metal Cover
(3400MA)
