3000 Series Door Closer
Models 3311 and 3511
Regular, Top Jamb, or Parallel Arms, Hold Open
Installation Instructions
Regular Arm
See page 3
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
Included Components (See page 2 for mounting hardware)
Dial
Screw
Closer
DA
Option
Pinion Cap
(Not included with
Slim Cover)
Legacy Friction Hold Open Arm
NOTE: Legacy FHO arm has
installation orientation.
See 80-9300-0003-000 for
details
To Determine Hand of Door:
Right Hand
Reverse
LEFT
RIGHT
HAND HAND
DOOR DOOR
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening, and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific
situation. When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated open-
ing, please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with
all applicable codes and ratings.
855-557-5078 x 2 • www.accentra-assaabloy.com
Copyright © 2004, 2017, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
80-9303-2207-010 Rev 3 05/24
Top Jamb Mount
Right Hand Door - RH
Left Hand Reverse - LHR
Shoe
Dial
Set
Screw
Hold Open
Arm
Arm
Assembly
1/8" Hex
Wrench
Screw Pack
To Determine Date Code:
Left Hand
Reverse
See page 4
Left Hand Door - LH
Right Hand Reverse - RHR
Plates
Main Arm
Pinion Screw
3148
Plate
Main Arm
Soffit Adapter Plate
Tools Needed
Date
Code
Parallel Arm
See page 5
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
Covers
588 Soffit Plate
(Used with Parallel
Arm Closers Only)
3400MA Architectural
3200P
Standard
Narrow Cover
3400P Standard
Full Cover or
3400M Standard
Full Metal Cover
Optional
3400A Architectural
Plastic Cover or
Metal Cover
