Appendix
15.2.4

Settings for Adapter Box G2

a. Select Menu>Settings>Advanced Settings>Peripheral Setstings>Solax485.
b. Select AdapBox G2 and set the Baud Rate and corresponding address. The
default Baud Rate is 9600.
=====Solax485=====
>Function Control
AdapBoxG2
• When two devices need to be connected at the same time, the braud rate and
address of the two devices shall be set to the same.
c. Check the connection status.
• For specific wiring and setting procedures of Adapter Box G2, refer to
User Manual
166
.
=====Solax485=====
>Baud Rate
9600
NOTICE!
=====Solax485=====
>AdapBox G2 COM STAT
Connected
NOTICE!
=====Solax485=====
>AdapBoxG2 Addr:
96
Adapter Box G2
