X3-Retro Fit
User Manual
8.0kW - 10.0kW

Copyright Declaration

Solax Power Network Technology(Zhe jiang) Co,. Ltd.
The copyright of this manual belongs to Solax Power Network Technology(Zhe jiang) Co,.
Ltd..
Any corporation or individual should not plagiarize, partitially or fully copy (including
software,etc.), and no reproduction or distribution of it in any form or by any means. All rights
reserved. SolaX Power Network Technology (Zhe jiang) Co.,Ltd. (SolaX Power Co.,Ltd.). reserves
614.00455.01
