SolaX Power X3-Hybrid-5.0-D User Manual
  1. Manuals
  2. Brands
  3. SolaX Power Manuals
  4. Inverter
  5. X3-Hybrid-5.0-D
  6. User manual

SolaX Power X3-Hybrid-5.0-D User Manual

Hide thumbs Also See for X3-Hybrid-5.0-D:
Table of Contents

Advertisement

Quick Links

Download this manual
SolaX Power Network Technology (Zhejiang) Co., Ltd.
ADD.: No. 288 Shizhu Road, Tonglu Economic Development Zone,
Tonglu City, Zhejiang Province, 310000 P. R. CHINA
Tel.: + 86 (0) 571- 56260011
E-mail: info@solaxpower.com
320101080601
X3-Hybrid Series
User Manual
5.0kW - 15.0kW
Copyright Declaration
The copy right of this manual belongs to SolaX Power Network Technology(Zhejiang) Co. , Ltd.(SolaX
Power Co. , Ltd. ) . Any corporation or individual should not plagiarize, partially or fully copy it
(including software, etc. ) , and reproduction or distribution of it shall not be allowed in any form or
by any means. All rights reserved. SołaX Power Network Technology (Zhejiang) Co. , Ltd. reserves the
right of nal interpretation. The contents are subject to change without prior notice.
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X3-Hybrid-5.0-D and is the answer not in the manual?

Questions and answers

Related Manuals for SolaX Power X3-Hybrid-5.0-D

Summary of Contents for SolaX Power X3-Hybrid-5.0-D

  • Page 1 SolaX Power Network Technology (Zhejiang) Co., Ltd. Copyright Declaration The copy right of this manual belongs to SolaX Power Network Technology(Zhejiang) Co. , Ltd.(SolaX ADD.: No. 288 Shizhu Road, Tonglu Economic Development Zone, Power Co. , Ltd. ) . Any corporation or individual should not plagiarize, partially or fully copy it (including software, etc.
  • Page 2 Change History Changes between document versions are cumulative. The latest version contains all updates made in previous versions. Version 01 (Nov. 01, 2023) Update 3 Technical Data (Added parameters of rated output apparent power and Max. output apparent power for AS/NZS 4777.2) Version 00 (Sep.

  • Page 3: Table Of Contents

    Contents Contents Note on this Manual ..........1.1 Scope of Validity ..............1.2 Target Group ................1.3 Symbols Used ................1.3.1 Important Safety Instructions..........1.3.2ExplanationofSymbols............1.3.3 CE Directives................ Introduction ..............2.1 Basic Features ................. 2.2 Electrical Block Diagram of the System ...... 2.3 Work Modes ................

  • Page 4: Target Group

    5.5 Communication Connection ............the product. Please read it carefully before operating. 5.5.1 Introduction to COM Communication........5.5.2 Introduction to Meter/CT Communication......X3-Hybrid-10.0-D 5.5.3 Parallel Communication..............X3-Hybrid-5.0-D X3-Hybrid-5.0-M X3-Hybrid-10.0-M X3-Hybrid-10.0K-D 5.5.4 Introduction to DRM communication........X3-Hybrid-12.0-D X3-Hybrid-6.0-D X3-Hybrid-6.0-M X3-Hybrid-12.0-M...
  • Page 5 Safety Safety Caution! Warning! “Caution” indicates a hazardous situation which, if not Before performing maintenance, cleaning or operation avoided, could result in minor or moderate injury. on the circuit connected to the inverter, authorized maintenance personnel must first disconnect the AC and DC power supplies of the inverter.
  • Page 6 Safety Safety All DC and AC power sources must be disconnected from the If the building installed with external light protection device is inverter for at least 5 minutes before any wiring or electrical far away from the inverter location, in order to protect the operation is performed on the inverter to ensure complete isolation inverter from electrical and mechanical damage, the inverter of the inverter and avoid electric shock.

  • Page 7: ExplanationOfSymbols

    Safety Safety 1.3.2 Explanation of Symbols Ø PE Connection and Leakage Current This section gives an explanation of all the symbols shown on the inverter and on the type label. • All inverter’s incorporate a certified internal Residual Current Monitoring (RCM) in order to protect against possible electrocution and fire hazard Symbols on the Inverter in case of a malfunction in the PV array, cables or inverter.

  • Page 8: Ce Directives

    Safety Safety 1.3.3 CE Directives This chapter describes the requirements of the European low Danger of high voltages. voltage regulations, including safety instructions and system Danger to life due to high voltages in the inverter! licensing conditions, the user must comply with these regulations when installing, operating, and maintaining the inverter, otherwise it will cause personal injury or death, and the inverter will cause Danger.

  • Page 9: Introduction

    Installation Introduction 2 Introduction Diagram B: N line and PE line separate wiring, M series inverter ; 2.1 Basic Features (For most countries) This high-quality inverter can convert solar energy into alternating current and store energy into batteries. PV 1 The inverter can be used to optimize self-consumption, stored in PV 2 Inverter...

  • Page 10: Work Modes

    Introduction Introduction 2.3 Work Modes Diagram D: N line and PE line together, M series inverter; 6:00 Forced The inverter has two con gurable working ( Applicable to Australia) charging periods: allowed discharging period and forced charging period. 24:00 12:00 PV 1 Allowed discharging...

  • Page 11: Dimensions

    Introduction Introduction Backup mode The back-up mode is suitable for areas For off-grid status, there is only one work mode: EPS (Off-grid). with frequent power outages. EPS (Off-grid) In case of power failure, the system will This mode will maintain the battery supply EPS loads through PV and battery.

  • Page 12: Terminals Of Inverter

    Introduction Technical Data 3 Technical Data 2.5 Terminals of Inverter 3.1 DC Input(apply to version D/M) X3-Hybrid-10.0 X3-Hybrid-5.5-D X3-Hybrid-12.0 X3-Hybrid-8.3-D Model X3-Hybrid-5.0 X3-Hybrid-6.0 X3-Hybrid-8.0 X3-Hybrid-15.0 X3-Hybrid-10.0K-D X3-Hybrid-12.0K-D Max. Recommended A:4000/B:4000 A:5000/B:5000 A:8500/B:5000 A:10500/B:6000 A:11000/B:7000 A:11000/B:8300 A:11000/B:7000 A:8000/B:5500 DC power [W] Max.

  • Page 13: Battery

    Technical Data Technical Data 3.3 Battery(apply to version D/M) 3.5 EPS(Off-grid) Output(apply to version D/M) X3-Hybrid-10.0 X3-Hybrid-12.0 X3-Hybrid-5.5-D X3-Hybrid-5.5-D X3-Hybrid-10.0 X3-Hybrid-12.0 X3-Hybrid-5.5-D X3-Hybrid-8.3-D Model X3-Hybrid-5.0 X3-Hybrid-6.0 X3-Hybrid-8.0 X3-Hybrid-15.0 Model X3-Hybrid-5.0 X3-Hybrid-6.0 X3-Hybrid-8.0 X3-Hybrid-15.0 X3-Hybrid-5.0-MX3-Hybrid-6.0-M X3-Hybrid-8.0-M X3-Hybrid-10.0-M X3-Hybrid-12.0-M X3-Hybrid-15.0-M X3-Hybrid-5.0-MX3-Hybrid-6.0-M X3-Hybrid-8.0-M X3-Hybrid-10.0-M X3-Hybrid-12.0-M X3-Hybrid-15.0-M X3-Hybrid-10.0K-D X3-Hybrid-12.0K-D X3-Hybrid-10.0K-D...

  • Page 14: Installation

    Installation Installation 4 Installation 4.1 Check for Transport Damage Number Quantity Description (for M series) Ensure that the inverter is in good condition via transportation. If there Inverter is any visible damage such as cracks, please contact the dealer Bracket immediately.

  • Page 15: Installation Precautions

    Installation Installation 4.3 Installation Precautions 4.4 Tool preparation The protection level of the inverter is IP 65, so that the inverter can be Tool equipment installed outdoors. Type Image Image Check the installation environment and pay attention to the following Name Name conditions when installing:...

  • Page 16: Installation Site Conditions

    Installation Installation 4.5 Installation Site Conditions 4.5.1 Installation Carrier Requirements Type Image Name Requirement Do not install the inverter near flammable materials. Please install the inverter on a solid object that can withstand the Equipment Grid port and EPS(Off-grid) port wiring Breaker weight requirements of the inverter and energy storage system.

  • Page 17: Installation Space Requirements

    Installation Installation 4.5.3 Installation Space Requirements 4.6 Mounting Reserve enough space when installing inverter (at least 300mm) for heat Preparation Ø dissipation. Please prepare the following tools before installation. ≥300mm Reserved space dimensions of installation Position Min Distance ≥300mm ≥300mm Left 300mm Right...
  • Page 18 Installation Installation Ø Step 3: Tighten the inverter and bracket e ) Hang the buckle at the back of the inverter onto the corresponding position of the bracket; f ) Use an Alley key to tighten the screw on the right side of the inverter. Φ8 Drill (Depth: 65 mm) Ø...

  • Page 19: Electrical Connections

    Electrical Connections Electrical Connections 5 Electrical Connections Ø Connection step 5.1 PV Connection The M series inverter has been connected with PV cables. For speci c The inverter have two PV inputs. Please select photovoltaic modules installation details, please refer to the X3-Matebox Quick Installation with good performance and quality assurance.
  • Page 20 Electrical Connections Electrical Connections Crimp pin contact by using the MC4 crimping tool. Step 7. Use a multimeter to measure the open circuit voltage of the Step 4. positive pole and negative pole of the PV cable, and make sure the open circuit voltage less than the permissive max input voltage MC4 crimping tool 4mm - 6mm...

  • Page 21: Grid Port And Eps(Off-Grid) Output Connection

    Electrical Connections Electrical Connections 5.2 Grid Port and EPS(Off-grid) Output Connection 5.3 EPS(Off-grid) Block Diagram The inverter is three-phase inverter. Suitable for rated voltage The inverter has an EPS(Off-grid) function. When the grid is connected, 380/400/415V, frequency 50/60Hz. Other technical requests the inverter outputs go through the Grid port, and when the grid is should comply with the requirement of the local public grid.
  • Page 22 Electrical Connections Electrical Connections Diagram B: N line and PE line separate wiring, M series inverters ; Diagram D: N line and PE line together, all load connection EPS(Off-grid) (For most countries) scheme; ( Applicable to Australia) PV 1 PV 1 PV 2 Inverter PV 2...
  • Page 23 Electrical Connections Electrical Connections Ø Ø Grid and EPS(Off-grid) connection steps EPS(Off-grid) load requirements Connection requirements Warning! Note: Check the grid voltage and compare the voltage range (see Ensure that the EPS(Off-grid) load rated power is within the technical data). Disconnect the circuit board from all power sources EPS(Off-grid) rated output power range, otherwise, the to prevent electric shock.
  • Page 24 Electrical Connection Electrical Connection Step 2. Remove the waterproof rubber stopper in the AC protective Step 3. Strip off 12mm insulation layer at one end of the two cables. Insert cover, and then thread the Grid and EPS(Off-grid) cables through the the ferrules into the stripped end of cables respectively, and finally use a corresponding Grid and EPS(Off-grid) ports of the cover.
  • Page 25 Electrical Connection Electrical Connection Step 4. Insert the L1, L2, L3, N wires of Grid cable into the corresponding Step 6. Tighten the swivel nuts of the AC protective cover. ports of the Grid terminal block, and insert the L1, L2, L3 wires of EPS (off- grid) into the corresponding ports of EPS terminal block.

  • Page 26: Battery Connection

    Electrical Connection Electrical Connection 5.4 Battery Connection Ø Connection requirements Ø Battery connection steps The inverter charge and discharge system can be equipped with Battery port connection line of the M series inverter is on the X3- high voltage lithium battery . Matebox, for specific installation details, please refer to the X3- Please note that the maximum voltage of the battery should not Matebox Quick Installation Guide It is necessary to wire the D series...
  • Page 27 Electrical Connection Electrical Connection Step 4. Press down the spring by hand and you can hear a “click” sound, Ø Communication connection (BMS port) and then push the ends together, and tighten the joints of the connectors. BMS port definition The communication interface between the inverter and the battery uses Spring Spring...

  • Page 28: Communication Connection

    Electrical Connection Electrical Connection 5.5 Communication Connection (COM/ Meter/ CT/ CAN1/ CAN2/ DRM/ OFF port) Ø Application occasion COM is a standard communication interface, through which the 5.5.1 Introduction to COM Communication monitoring data of the inverter can be directly obtained. Also, external COM communication interface is mainly provided for customization the communication devices can be connected to carry out the secondary second step of development use.The inverter supports the control of...

  • Page 29: Introduction To Meter/Ct Communication

    Electrical Connection Electrical Connection 5.5.2 Introduction to Meter/CT Communication CT Connection Ø The inverter should work with an electric meter or current sensor (CT for The current sensor measures the current on the live wire between the short) to monitor household electricity usage. The electricity meter or CT inverter and the public grid.

  • Page 30: Parallel Communication

    Electrical Connection Electrical Connection 5.5.3 Parallel Communication (CAN1/CAN2 port) Note for CT connection: The inverter provides a parallel function. 10 inverters can be maximally connected in diagram 1. And diagram 2 allows up to three Note! inverters to be connected. In these two systems, one inverter will be •...
  • Page 31 Electrical Connection Electrical Connection Ø Work Modes in Parallel System There are three work modes in parallel system, and your acknowledge of different inverter’s work modes will help you understand parallel system better, therefore please read it carefully before operating. Only if no one inverter is set as a “Master”, all inverters are in Free mode free mode in the system.
  • Page 32 Electrical Connection Electrical Connection For diagram 1 Step 2: Connect the power cable between X3-PBOX-60kW/150kW- G2 and inverter (R/S/T/N/PE) in diagram 1. Step1: Connect all inverters’ communication together by -If the user purchased the X3-PBOX-60kW/150kW-G2 product, please connecting network cables between CAN ports. refer to the X3-PBOX-60kW/150kW-G2 user manual for installation - Use standard network cables for CAN-CAN connection and insert and connection.
  • Page 33 Electrical Connection Electrical Connection Ø Ø How to Remove parallel system Parallel Control Function If one inverter wants to exit from this parallel system, please do the steps Master inverter has an absolute lead in the parallel system to control as below: all slave inverter’s energy management and dispatch control.

  • Page 34: Introduction To Drm Communication

    Electrical Connection Electrical Connection 5.5.4 Introduction to DRM communication (AS4777 regulatory requirements) 5.5.6 Communication Connection Steps DRM requirements: Meter/CT connection steps: Step1: Prepare a waterproof connector with RJ45, a RJ45 terminal and a Requirement Mode communication cable. An additional RJ45 terminal is not needed in meter DRM0 Operation disconnect device connection.
  • Page 35 Electrical Connection Electrical Connection Step2: Remove the dustproof cover from the Meter/CT port. Insert the communication cable into the Meter/CT port. An audiable "Click" will be heard if it is successfully connected. Upgrade/Dongle Step3: For a CT connection, plug the terminal B to RJ45 connector. For a meter connection, connect pin 4 and pin 5 of the stripped end directly to the pin 24 and pin 25 of a meter.
  • Page 36 Electrical Connection Electrical Connection CAN1/ CAN2/ DRM/ OFF port connection steps: Step 4. Crimp each stripped cables with a RJ45 terminal in accordance with CAN1/ CAN2/ DRM/ OFF pin definition. Step 1. Prepare a communication cable, and then take out RJ 45 terminals in the accessory bag.
  • Page 37 Electrical Connection Electrical Connection Step 5. Insert well crimped CAN1/ CAN2/ DRM/ OFF cables into the Step 6. Tighten the screws and lock the cover on the inverter. And corresponding port of the inverter. then tighten the swivel nuts. Upgrade/Dongle CAN1 CAN2 DRM Upgrade/Dongle...

  • Page 38: Grounding Connection(Mandatory)

    Electrical Connection Electrical Connection 5.6 Grounding Connection (Mandatory) Step 7: Here below are the well connected communication cables. The user must make two ground connections: one shell grounding, and one equipotential grounding. This prevents electric shock. Note: If the PV cable from the inverter is not connected to the earth, the inverter will turn on a red light Inspect and report ISO Fault.
  • Page 39 Electrical Connection Electrical Connection Step 3. Insert the striped cable into OT terminal and tighten the terminal Step 4. Connect the ground cable to the inverter lock the terminal with a terminal crimping tool. with an Alley key. Grid Grid CAN LCD DRM CAN LCD DRM Upgrade/Dongle...

  • Page 40: Monitoring Connection(Accessories)

    Electrical Connection Electrical Connection 5.7 Monitoring Connection (Accessories) Step 2. Plug Wifi Dongle into the DONGLE port. The inverter provides a DONGLE port, which can transmit data of the inverter to the monitoring website via Wifi Dongle, 4G Dongle and LAN Dongle. (If necessary, purchase products from us.) Ø...
  • Page 41 Electrical Connection Electrical Connection • To turn off the DC switch Ø DC Switch for Australia i) Rotate the DC switch from ON state to OFF state. The Australian version includes 3 states: ON, OFF, and OFF+Lock. The DC switch is in the OFF state by default. CAN1 CAN2 Upgrade/Dongle...

  • Page 42: Check All Below Steps Before Starting Inverter

    Electrical Connection Electrical Connection 5.8 Check All below Steps before Starting Inverter • To unlock the DC switch Ø After the inverter is checked, then conduct the following steps I) Remove the lock. ii) Push the lock down (as shown in the diagram below). Make sure that the inverter is fixed on the wall.

  • Page 43: Inverter Operation

    Electrical Connection Electrical Connection 5.9 Inverter Operation Ø Before operation, check the inverter according to the If it is the rst time to boot, please follow the prompts to enter the setting interface. following steps a) Check that the inverter is well xed on the wall. Warning! b) Ensure that all ground wires are well tightened.
  • Page 44 Firmware Upgrading Firmware Upgrading 6 Firmware Upgrade Ø 2) Please contact our service support to obtain the firmware, and store the Upgrade notes firmware in the U disk according to the following path. Please read the following precautions before upgrading. Update: For ARM le: “update \ARM\618.00406.00_HYB_3P_ARM_V1.13_1220.usb”;...

  • Page 45: Firmware Upgrading

    Firmware Upgrading Firmware Upgrading Step 5. For DSP: Please wait for 10 seconds. When "Update" page shown as below, press down to select "DSP" and then press Enter. Please confirm the firmware version again and press Enter to upgrade. The upgrade takes about 2 minutes.

  • Page 46: Setting

    Setting Setting 7.2 Menu Structure 7 Setting 7.1 Control Panel Date & Time System ON/OFF Language Self Use EPSMute Feed-in priority Self Use Mode Backup mode Forced Discharge Feed-in Priority Manual Forced Charge Backup Mode Peak Shaving Stop Chr & Dischrg Char &...

  • Page 47: Lcd Operation

    Setting Setting 7.3 LCD Operation The main inter face is the default inter face, the inver ter will Ø Menu main automatically return to this interface when the system started up successfully or not operated for a period of time. System ON/OFF The information of the interface is as below.
  • Page 48 Setting Setting Ø Work Mode Manual Self Use This work mode is for the after-sales team to do after-sales maintenance. Feed-in Priority Work Mode Manual mode, there are three options to choose from: forced Backup Mode >Work Mode charging, forced discharge, stop charging and discharging (grid- Self Use connected power).
  • Page 49 Setting Setting Ø For off-grid status, there is only one work mode: EPS (Off-grid). System Status EPS (Off-grid) In case of power failure, the system will supply EPS loads through PV and battery. (The battery must be installed, and EPS loads shall not exceed battery’s max.
  • Page 50 Setting Setting 4 ) On-grid Ø Parallel Status Here you can see the voltage, current, frequency, and power of the Status shows on the screen when paralleling. grid. Parallel Status On-grid A On-grid B Slaver1 0.0V 0.0V Slaver2 0.0A 0.0A Slaver3 PaOut PbOut...
  • Page 51 Setting Setting Here you can set the inverter time, language, working modeSOC, charging and discharging time period and user password. Today: Total: 0.0 KWh 0.0 KWh User Setting Date & Time 3 ) E_Feedin > Language E_Feedin Here you can see the inverter's electricity EPS mute >FeedInToday sold, total electricity sold, electricity...
  • Page 52 Setting Setting 7 ) Charge and discharge time Self Use Mode Self Use Mode Here you can set the charge and discharge time period. ＞Min SOC： If two charging and discharging periods are needed, turn on the charging Min SOC Charge from grid and discharging period 2 and set the period.
  • Page 53 Setting Setting User Setting Peak shaving mode DisChgPeriod1 Load Management Load Management >DisChgPeriod1 ShavingStartTime Thresholds on DisChgPeriod2 Thresholds off ＞ Peak shaving mode ChargeFromGrid Feedin power Consumption 07:00 Reserved_SOC 3000W 500W Peak shaving mode DisChgPeriod1 DisChgPeriod1 Load Management Load Management DisChgPeriod1 ShavingLimits1 ShavingEndTime...
  • Page 54 Setting Setting Ø Advance setting Enter Country Country ☆ Safety Code Parallel Setting >Safety **Previous page >AS4777_2020_A< >AS4777_2020_A< Back Grid Parameters Main Breaker Limit Down Charger Phase Unbalanced Country Export Control EPS(Off-grid) Setting >AS4777_2020_B< Meter/CT Settings AS 4777 Setting Down Self Test Country ExternalGen...
  • Page 55 Setting Setting 2 ) Grid Parameters OFPL_Setting OFPL_Setting OFPL_Setting Setting path: Main -> Setting -> Advance Setting -> Grid Parameters. W(Gra) Tstop fstop-disch 00.00Hz 0.0S Here you can set the protection value of grid voltage and frequency. UFPL_Setting The default value is the specified value under the current safety OFPL_Setting Grid Parameters regulations, and the user cannot change it.
  • Page 56 Setting Setting 3 ) Charger 5 ) Meter/CT Settings Here the user can set the parameters of charger on this page, the The user needs to select the CT or electricity meter to connect the inverter is compatible with both lithium battery. Users can set the inverter here.
  • Page 57 Setting Setting 6 ) Self Test (only for CEI 0-21) Ovp_10(59.S1)test Self Test The self test function allows users to test the following items. "Full test", 0.0V Tt: 0ms "Ovp(59.S2) test"27. "Uvp (s1) test", "Uvp (27. s2) test", "Ofp (81> .S1) test", Test Report 0.0V To: 0ms "Ufp (81 <.S1) test", "Ufp (81>...
  • Page 58 Setting Setting 7 ) GMPPT Mode Comment Here, you can set the shadow tracking with four options, which are off, low, middle, and high. Over-Excited PF value Under-Excited PF value GMPPT GMPPT P1_PF PV1 Control PV2 Control P2_PF OFF/Low/Middle/High OFF/Low/Middle/High P3_PF P4_PF 8 ) Modbus...
  • Page 59 Setting Setting 11 ) PU Function (applicable to specific countries, please refer to 12 ) FVRT Function(apply to50549) local grid requirements) Here you can set the high and low enable or disable. The PU function is a volt-watt response mode required by certain FVRT Function FVRT Function FVRT Function...
  • Page 60 Setting Setting *) If the grid-connected power of the inverter ≤4.6kW, the Power Factor is 0.95 at 16 ) Main Breaker Limit 1.0 power; if the grid-connected power of the inverter > 4.6kW, the Power Factor is For power limit of smart meter or CT, the current must be set in line 0.90 at 1.0 power.
  • Page 61 Setting Setting 19) AS 4777 Setting External Gen External Gen External Gen External Gen Allowed Disc Period Forced Charg Period Forced Charg Period Allowed Disc Period It is the same as the function of Export Control, but it’s only applicable End Time End Time Start Time...
  • Page 62 Setting Setting 21 ) Reset 23 ) Extend BAT FUNC This function is for extending new batteries. This setting shall be Users can reset the reset error log, meter power ,inverter power, and invalid under the EPS mode. When it is on-grid, enabling this setting restore factory settings here.
  • Page 63 Setting Setting Ø a ) About About Here you can see some basic information of the inverter and battery. such as the inverter and battery SN number, software version number, and system run time. About Inverter SN >Inverter Battery Register SN Internal code Inverter Inverter...
  • Page 64 Setting Setting Battery Ø Information ☆ Battery Battery Select Region >Internal Code: Enter Enter Enter > > Bat_M SN BatBrand:BAK >Menu >Information 6S012345012345 Back Back AS4777_2020_C ARM:3.17 DSP: 3.18 Back Down >ResponseV2 >ResponseV1 >ResponseV4 >ResponseV3 Battery Battery 260.0 V 253.0 V 215.0 V 207.0 V Down...

  • Page 65: Troubleshooting

    Troubleshooting Troubleshooting 8 Troubleshooting Number DCI overcurrent protection fault. 8.1 Troubleshooting IE 09 DCI OCP Fault • Wait for a while to check if it's back to normal. • Or ask the installer for help. This section contains information and procedures for resolving DCV EPS(Off-grid) overvoltage protection failure.
  • Page 66 Troubleshooting Troubleshooting Number Number NTC invalid Mgr InterCom Fault Make sure the NTC is properly connected and the NTC is in good • IE 25 InterComFault • Shut down photovoltaic, battery and grid, reconnect. condition. IE 105 NTC Sample Invalid •...
  • Page 67 Troubleshooting Troubleshooting Number Number Battery Unbalanced Failure Battery temperature sensor malfunction BE 26 CellImblance BMS Tempdiff BE 09 Please contact the battery supplier. • Please contact the battery supplier. • Battery hardware protection failure Battery Unbalanced Failure BE 10 BMS_Hardware BMS_BreakFault BE 27 •...

  • Page 68: Routine Maintenance

    Troubleshooting Decommissioning 9 Decommissioning 8.2 Routine Maintenance 9.1 Disassembling the Inverter Inverter do not require any maintenance or correction in most cases, but if the inverter often loses power due to overheating, this can be attributed to the following reason: Remove DC input line and AC output line of inverter.

  • Page 69: Disclaimer

    Disclaimer Warranty Registration 10 Disclaimer Form The hybrid inverters are transported, used and operated under limited condition, such as environmental, electrical etc. Our For Customer (Compulsory) company shall not be liable to provide the service, technical support or compensation under conditions listed below, including but not Country Name limited to:...
  • Page 70 PLEASE REGISTER THE WARRANTY IMMEDIATELY AFTER INSTALLATION! GET YOUR WARRANTY CERTIFICATE FROM DURACELL! KEEP YOUR INVERTER ONLINE & WIN DURACELL POINTS! Open your Wait for the camera app camera to and point recognize your device the QR code at the QR code Notification Click the notification banner...

This manual is also suitable for:

X3-hybrid-5.0-mX3-hybrid-6.0-dX3-hybrid-6.0-mX3-hybrid-8.0-dX3-hybrid-8.0-mX3-hybrid-10.0-d ... Show all

Table of Contents
