EPS Settings
Select and enter EPS Setting interface and set Frequency, Min SOC, Min ESC SOC and
Super Backup.
Frequency: Default: 50 Hz. Output frequency of EPS
•
• Min SOC: Default: 10%, range: 10%-100%
»
If the battery SOC is lower than the Min SOC, the inverter will prompt
BatPowerLow and turn off if there is no PV input.
• Min ESC SoC: Default: 30%, range: 15%-100%
»
In EPS mode, the minimum SOC required for re-entry EPS mode after
BatPowerLow prompted. When the battery SOC reaches the Min ESC SOC
through charging from PV, the inverter will automatically enter EPS mode
from EPS Waiting mode.
• Super Backup: This function is disabled by default. When an inverter is in EPS
mode and no battery is successfully connected to the inverter, you need to
enable the function.
• In Super Backup, loads acquire energy from PVs, which are instable and single-phase.
When a user increases or decreases the loads, the system probably reports an error
of Bus Volt Fault or Over Load Fault, which is a common phenomenon and should
be neglected.
Battery Settings
Setting Charge
The inverter is compatible with lithium-ion battery. You can set the charge & discharge
parameters of battery.
• Max Charge: Maximum charging current of battery
• Max Discharge: Maximum discharging current of battery
Charger upper limit: The maximum charging limit. Default: 100%, range: 10%-
•
100%.
=====EPS Setting=====
>Frequency
50Hz/60Hz
=====EPS Setting=====
>Min ESC SoC
30%
=====EPS Setting=====
>Min SoC
=====EPS Setting=====
>Super Backup
Disable/Enable
NOTICE!
Operation on LCD
10%
