Specification - Duplo DPC-600PKG Installation And Operation Manual

1. Introduction
The SF-300i feeder is an automatic air suction, top-feed feeder that offers cost effective and
increase thruput of the DPC-600PKG flat bed cutter for B

2. Specification

Specifications
Max. Paper Width
Max. Paper Length
Min. Paper Width
Max. Thickness
Paper Weight
Min Paper Size
Power Requirement
Dimension
Weight
3. Name Plate
Part I SF-300i Suction Feeder
77.3" x 35.4" x 39.8" (1964 x 900 x 1012.6mm)
- 5 -
ox-on-Demand.
SF-300i Suction Feeder
23"
29.5"
12"
0.14" (3.6mm)
200gsm
17 x 11" (Long edge feed)
110VAC, 50/60HZ 1.9A
342 lbs (155Kgs)
