Mec Micro19-XD Service & Parts Manual page 91

Section 18 - Electrical System
Item
Part Number
1 42481
2 42540
3 43755
4 42484
5 41921
6 41919
7 41917
8 42485
9 42486
10 42487
11 42488
12 42489
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34 42483
42883
35
47281
36 47282
Page 87
Description
ECU Harness
Accessories Harness
Lowering Valve Harness
Drive Motor Harness
Pump Motor Positive Harness
Pump Motor Negative Harness
Motor Controller Harness
DC Contactor Harness
Fuse Harness
Battery Positive Harness
Battery Harness
Battery Negative Harness
REF Ground Control Assembly (Refer to page 56)
REF Pressure Sensor (Refer to page 80)
REF Limit Switch, Pothole (Refer to page 58)
REF Rotary Sensor (Refer to page 58)
REF Tilt Sensor (Refer to page 58)
REF Beacon (Refer to page 58)
REF Platform Control Box Assembly (Refer to page 74)
REF Hydraulic Power Unit (Refer to page 52)
REF Horn (Refer to page 50)
REF Alarm (Refer to page 50)
REF Coil (Refer to page 80)
REF Coil (Refer to page 82)
REF Left Motor (Refer to page 42 or page 46)
REF Right Motor (Refer to page 42 or page 46)
REF Motor Controller (Refer to page 54)
REF Motor (Refer to page 52)
REF DC Contactor (Refer to page 54)
REF 200A Fuse Assembly (Refer to page 54)
REF Power Switch (Refer to page 50)
REF Battery (Refer to page 50)
REF Charger (Refer to page 50)
Harness, Communications
Screw Terminal Connector (Serial #1610100 to 16101800)
Connector, Drive Motor (From Serial #16101801)
Terminal (For 47281 Only)
REF - Reference
Micro19-XD - Service & Parts Manual - 43894
August 2024
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
2
2
4
