Section 3 - Torque Specifications
Note: Always lubricate threads with clean hydraulic fluid prior to installation.
Use the following values to torque hydraulic components when a specific value is not available.
Always check for torque values in the following places before relying on the Hydraulic Components
Torque Table.
• Parts drawings and service instructions in this manual.
• Packaging and instruction sheets provided with new parts.
Instruction manuals provided by the manufacturer of the component being serviced.
•
SAE Port Series
#4
#6
#8
#10
#12
#16
Page 6

Hydraulic Components Torque Table

Cartridge Poppet
Ft-lbs Nm
N/A N/A
N/A N/A
25 - 30 31 - 41
35 - 40 47 - 54
85 - 90 115 - 122
130 - 140 176 - 190
Micro19-XD - Service & Parts Manual - 43894
Fittings
Ft-lbs Nm
N/A N/A
10 - 20 14 - 27
25 - 30 34 - 41
35 - 40 47 - 54
85 - 90 115 - 122
130 - 140 176 - 190
August 2024
Hoses
In-lbs Nm
135 - 145 15 - 16
215 - 245 24 - 28
430 - 470 49 - 53
680 - 750 77 - 85
950 - 1050 107 - 119
1300 - 1368 147 - 155
