03-05-2024 07:55
TVM 3420 Series
TVM 3440 Series
TVM 3620 Series
TVM 3640 Series
Full Installation Guide
Everything you need to get your TV safely on the wall, in no time
Before you start
...we just wanted to say thanks for choosing Vogel's. Smart choice.
And you're already making another smart choice – reading the manual! Keep reading to learn all
about safe, efficient installation, and how to use your new mount.
Stay safe
https://manuals.vogels.com/en-us/tvm3420_3440_3620_3640.html
Warning
Always read these safety instructions carefully before installing and using this product.
Following these instructions is strictly required. Incorrect mounting and/or installation could
put you, your TV, and your family at substantial risk.
Don't dare risk it... Read all
TVM 3420 Series
1/18
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for vogel's Comfort TVM 3420 Series
Summary of Contents for vogel's Comfort TVM 3420 Series
- Page 1 03-05-2024 07:55 TVM 3420 Series TVM 3420 Series TVM 3440 Series TVM 3620 Series TVM 3640 Series Full Installation Guide Everything you need to get your TV safely on the wall, in no time Before you start …we just wanted to say thanks for choosing Vogel’s. Smart choice. And you’re already making another smart choice –...
-
Page 2: What's In Your Box
03-05-2024 07:55 TVM 3420 Series Vogel’s recommends that the mounting and/or installation of this product should be carried out by a suitably qualified expert. Vogel’s cannot be held responsible for any injury and/or damage caused by incorrect installation. Please consult the manual for your TV and ensure that the weight and size of the TV is within the maximum weight and size limits specified for this product, and that the TV mounting bolts used are of a suitable length and diameter. - Page 3 03-05-2024 07:55 TVM 3420 Series D. Safety instructions E. Bolts for fastening strips on TV (see contents below) F. Spacers G. Washers Ø 18mm H. Screws I. Plugs (fischer© DuoPower) J. Washers Ø 22mm K. Covers L. Protective TV patches M.
- Page 4 03-05-2024 07:55 TVM 3420 Series Got your tools ready? Don’t start without all the necessary tools: Large crosshead screwdriver Drilling machine 10mm or 25/64” concrete / brick drill (for concrete / brick walls only) 5mm or 13/64” concrete / brick drill (for concrete / brick walls only) 5mm or 13/64”...
- Page 5 03-05-2024 07:55 TVM 3420 Series Ready… set… get installing! Step 1: Attach the strips to the TV 1. Carefully place the TV face down, on a soft clean surface without any obstacles. 2. Fix the protective TV patches Ⓛ onto the vertical strips Ⓒ. Screw the strips Ⓒ onto the TV with the bolts Ⓔ.
- Page 6 03-05-2024 07:55 TVM 3420 Series 3. Loosen the pre-attached bolts Ⓒ with the allen key Ⓞ. 4. For models where the interface screws are pre-attached: remove both interface screws Ⓟ from the horizontal bars Ⓑ. 5. Slide the horizontal bars Ⓑ through the designated spacing of the vertical strips Ⓒ. Make sure the bars Ⓑ...
- Page 7 03-05-2024 07:55 TVM 3420 Series 1. Find the perfect spot for drilling with our DrillRight app (https://www.vogels.com/DrillRight) and the included drilling template. 2. Drill the holes. Pre-drill with a smaller drill to avoid damage to the wall. How deep do you drill? Check if the entire screw (except its head) fits in the hole before placing the plugs.
- Page 8 03-05-2024 07:55 TVM 3420 Series 4. Place the covers Ⓚ. Walls with wooden studs 1. Don’t just guess! Always use a stud finder to determine the position of studs. 2. Find the perfect spot for drilling by positioning the holes marked on the drilling template horizontally centered on a stud.
- Page 9 03-05-2024 07:55 TVM 3420 Series 5. Attach the wall mount Ⓐ to the wooden studs with the screws Ⓗ and washers Ⓙ. Use the spirit level Ⓞ to level the wall mount. Lubricate the screws for easy screwing in. 6. Place the covers Ⓚ. Other wall type / I don’t know my wall type https://manuals.vogels.com/en-us/tvm3420_3440_3620_3640.html 9/18...
- Page 10 03-05-2024 07:55 TVM 3420 Series If your wall is a little special – for example, hollow bricks, metal stud walls, wood panels or plasterboard – visit information for different wall types (https://www.vogels.com/en/c/tv/tv-on-the-wall). If you aren’t sure, don’t worry! Just ask your installer, specialist supplier or the Vogel’s Consumer Care team at www.vogels.com/contact (http://www.vogels.com/contact).
- Page 11 03-05-2024 07:55 TVM 3420 Series 2. Position the bottom interface screw Ⓟ through the hole in the wall mount Ⓐ and in the bottom bar Ⓑ. 3. Fasten both interface screws Ⓟ, optionally with an allen key. Make sure the TV is levelled using the spirit level.
- Page 12 03-05-2024 07:55 TVM 3420 Series Vertical and horizontal correction 1. Vertical correction: If the tilt option is not used and the screen still tilts downwards / upwards: tighten / loosen screw Ⓢ with an allen key until the screen is vertically leveled. 2.
- Page 13 03-05-2024 07:55 TVM 3420 Series Tilt to avoid reflections 1. Click the TiltAnchor™ button to release the TV from home position. 2. Adjust the tilt angle. Gently pull the top of the screen forward. Do not force the screen in the other direction. https://manuals.vogels.com/en-us/tvm3420_3440_3620_3640.html 13/18...
- Page 14 03-05-2024 07:55 TVM 3420 Series Guide your cables 1. Guide the cables. 2. Place the cable clip Ⓜ over the cables on the lower arm. 3. Place the wall cable clip Ⓝ over the cables on the wall plate. 4. Make sure your cables have enough slack for the TV mount to rotate in all directions. Carefully check if the cables and cable clips do not obstruct the movement of the hinges.
-
Page 15: Simple Troubleshooting
03-05-2024 07:55 TVM 3420 Series Again, lifting your TV is a two-person job. Always get help. Confused? Unsure? Going crazy? There’s plenty of help waiting for you, online: info@vogels.com (mailto:info@vogels.com) www.vogels.com/contact (http://www.vogels.com/contact) facebook.com/ VogelsForSure/ (https://www.facebook.com/VogelsForSure/) instagram.com/ vogels_official/ (https://www.instagram.com/vogels_official/) www.youtube.com/ c/VogelsForSure (https://www.youtube.com/c/VogelsForSure) Simple troubleshooting Found a problem you can’t fix? Don’t panic…... - Page 16 FAQs ‘Where can I request the correct bolts for my TV (a service kit)?’ Whatever you need, simply contact your local Vogel's dealer or Vogel's. Click here (http://www.vogels.com/contact) to contact Vogel's Consumer Care. ‘Where can I find installation videos?’...
- Page 17 ‘Which bolts or screws do I need to use?’ Use all wall screws and four bolts for securing your TV. Vogel's offers a complete assembly kit with all mounting materials included in the box, for both your TV and wall. Do you miss the correct bolts for your TV? Please contact your local Vogel's dealer.
- Page 18 If the product has not been installed or used in accordance with the instructions; If applicable, if the holes in the wall have not been properly drilled in accordance with the Vogel's installation instructions for the applicable wall type; If the product has been altered or repaired by someone other than Vogel’s;...
