2023-08-21 11:39
TVM 3420 Series
TVM 3440 Series
TVM 3620 Series
TVM 3640 Series
Full Installation Guide
Everything you need to get your TV safely on the wall, in no time
Before you start
...we just wanted to say thanks for choosing Vogel's. Smart choice.
And you're already making another smart choice – reading the manual! Keep
reading to learn all about safe, efficient installation, and how to use your new
mount.
https://manuals.vogels.com/en-us/tvm3420_3440_3620_3640.html
TVM 3420 Series
Additional tools
Click to download the app
(https://www.vogels.com/en-us/c/tvmountguide)
Click to watch
(https://youtu.be/ueE93t1vt_o)
1/18
Advertisement
Related Manuals for vogel's TVM 3420 Series
Summary of Contents for vogel's TVM 3420 Series
- Page 1 2023-08-21 11:39 TVM 3420 Series TVM 3420 Series TVM 3440 Series TVM 3620 Series TVM 3640 Series Additional tools Full Installation Guide Everything you need to get your TV safely on the wall, in no time Click to download the app (https://www.vogels.com/en-us/c/tvmountguide)
- Page 2 2023-08-21 11:39 TVM 3420 Series Stay safe Warning Always read these safety instructions carefully before installing and using this product. Following these instructions is strictly required. Incorrect mounting and/or installation could put you, your TV, and your family at substantial risk.
- Page 3 2023-08-21 11:39 TVM 3420 Series What’s in your box? Something missing? Make sure your packaging has everything in place: A. Wall mount B. Horizontal bars C. Vertical strips D. Safety instructions E. Bolts for fastening strips on TV (see contents below) F.
- Page 4 2023-08-21 11:39 TVM 3420 Series 4x M6*12mm bolts 4x M6*25mm bolts 4x M6*35mm bolts 4x M8*12mm bolts 4x M8*25mm bolts 4x M8*45mm bolts 4x M6 washer 4x spacer 10mm 4x spacer 5mm You just need four bolts to mount your TV. Store the rest for other use! Got your tools ready? Don’t start without all the necessary tools:...
- Page 5 2023-08-21 11:39 TVM 3420 Series Take care of your safety Who cares about looking cool? Always wear personal protective equipment: Eye protection Ear protection Safety shoes Lifting your TV is a two-person job. Don’t be bold! Additional tools Mark the first...
- Page 6 2023-08-21 11:39 TVM 3420 Series Ready… set… get installing! Step 1: Attach the strips to the TV 1. Carefully place the TV face down, on a soft clean surface without any obstacles. 2. Fix the protective TV patches Ⓛ onto the vertical strips Ⓒ. Screw the strips Ⓒ onto the TV with the bolts Ⓔ. Make sure the strips Ⓒ...
- Page 7 2023-08-21 11:39 TVM 3420 Series 3. Loosen the pre-attached bolts Ⓒ with the allen key Ⓞ. 4. For models where the thumbnuts are pre-attached: remove both thumbnuts Ⓟ from the horizontal bars Ⓑ. 5. Slide the horizontal bars Ⓑ through the designated spacing of the vertical strips Ⓒ. Make sure the bars Ⓑ are placed in a centered position.
- Page 8 2023-08-21 11:39 TVM 3420 Series 1. Find the perfect spot for drilling with our DrillRight™ AR app (https://www.vogels.com/DrillRight) and the included drilling template. 2. Drill the holes. How deep do you drill? Check the length of the screw (not the plug!) to find the right depth – this stops things from breaking.
- Page 9 2023-08-21 11:39 TVM 3420 Series 3. Attach the wall mount Ⓐ to the wall with the screws Ⓗ, washers Ⓙ and plugs Ⓘ. Use the spirit level Ⓞ to level the wall mount. Lubricate the screws for easy screwing in.
- Page 10 2023-08-21 11:39 TVM 3420 Series 2. Find the perfect spot for drilling with our DrillRight™ AR app (https://www.vogels.com/DrillRight) and the included drilling template. Don’t destroy your belongings! The wall mount must always be attached to the studs. 3. Now for the fun part… drilling the holes.
- Page 11 2023-08-21 11:39 TVM 3420 Series 5. Place the covers Ⓚ. Other wall type / I don’t know my wall type If your wall is a little special – for example, hollow bricks, metal stud walls, wood panels or plasterboard – or you simply aren’t sure, don’t worry! Just ask your installer, specialist supplier or the Vogel’s Consumer Care team at www.vogels.com/contact...
- Page 12 2023-08-21 11:39 TVM 3420 Series 1. Carefully lift and attach the TV to the wall mount Ⓐ. Place the upper thumbnut Ⓟ in the top notch of the wall mount. 2. Position the bottom thumbnut through the hole in the wall mount and in the bottom bar.
- Page 13 2023-08-21 11:39 TVM 3420 Series Vertical and horizontal correction 1. Vertical correction: If the tilt option is not used and the screen still tilts downwards / upwards: tighten / loosen screw Ⓢ with an allen key until the screen is vertically leveled.
- Page 14 2023-08-21 11:39 TVM 3420 Series Guide your cables 1. Guide the cables. 2. Place the cable clip Ⓜ over the cables on the lower arm. 3. Place the wall cable clip Ⓝ over the cables on the wall plate. Removing your TV 1.
-
Page 15: Simple Troubleshooting
2023-08-21 11:39 TVM 3420 Series Again, lifting your TV is a two-person job. Always get help. Confused? Unsure? Going crazy? There’s plenty of help waiting for you, online: info@vogels.com (mailto:info@vogels.com) www.vogels.com/contact (http://www.vogels.com/contact) facebook.com/ VogelsForSure/ (https://www.facebook.com/VogelsForSure/) instagram.com/ vogels_official/ (https://www.instagram.com/vogels_official/) www.youtube.com/ c/VogelsForSure (https://www.youtube.com/c/VogelsForSure) Simple troubleshooting Found a problem you can’t fix? Don’t panic…... - Page 16 It can also be found on our YouTube channel: www.youtube.com/c/VogelsForSure (http://www.youtube.com/c/VogelsForSure) ‘What if I need spare parts?’ If you require a spare part, please contact your local dealer or Vogel's. Click here (http://www.vogels.com/contact) to contact Vogel's Consumer Care. https://manuals.vogels.com/en-us/tvm3420_3440_3620_3640.html...
- Page 17 Use all wall screws and four bolts for securing your TV. Vogel's offers a complete assembly kit with all mounting materials included in the box, for both your TV and wall. Do you miss the correct bolts for your TV? Please contact your local Vogel's dealer. Click here (http://www.vogels.com/contact) to contact Vogel's Consumer Care.
- Page 18 Vogel’s guarantee shall lapse in the following cases: If the product has not been installed or used in accordance with the instructions; If applicable, if the holes in the wall have not been properly drilled in accordance with the Vogel's installation instructions for the applicable wall type;...
