TVM 7655 Series
Full Installation Guide
Everything you need to get your TV safely on the wall, in no time
Before you start
...we just wanted to say thanks for choosing Vogel's. Smart choice.
And you're already making another smart choice – reading the manual! Keep reading to learn all
about safe, efficient installation, and how to use your new mount.
Stay safe
Warning
Always read these safety instructions carefully before installing and using this product.
Following these instructions is strictly required. Incorrect mounting and/or installation could
put you, your TV, and your family at substantial risk.
Don't dare risk it... Read all
Vogel's recommends that the mounting and/or installation of this product should be
carried out by a suitably qualified expert.
Vogel's cannot be held responsible for any injury and/or damage caused by incorrect
installation.
Please consult the manual for your TV and ensure that the weight and size of the TV is
within the maximum weight and size limits specified for this product, and that the TV
mounting bolts used are of a suitable length and diameter. Note that not all the TV
mounting accessories provided are required for the installation of any one TV.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for vogel's TVM 7655 Series
Summary of Contents for vogel's TVM 7655 Series
- Page 1 TVM 7655 Series Full Installation Guide Everything you need to get your TV safely on the wall, in no time Before you start …we just wanted to say thanks for choosing Vogel’s. Smart choice. And you’re already making another smart choice – reading the manual! Keep reading to learn all about safe, efficient installation, and how to use your new mount.
-
Page 2: What's In Your Box
The wall mounting accessories provided are exclusively intended for installation on walls made of solid brick, solid concrete or solid wood columns. Any material covering the wall must not exceed 3mm/ 0.12 inch. For mounting on walls made of other materials, such as hollow bricks, wood panels or plasterboard, please consult your installer and/or specialist supplier. - Page 3 V. Drilling template Contents of the TV fasteners kit: 4x M6x12mm 4x M6x25mm 4x M6x35mm 4x M8x12mm 4x M8x25mm 4x M8x45mm 4x M6x18mm washer 4x spacer 10mm 4x spacer 5mm Need a long HDMI cable? Or a Cable Cover to hide your wall cables? Visit us online and order the right accessories directly through our website (https://www.vogels.com/en- gb/c/tv-bracket-accessories).
- Page 4 70mm / 2.8” (⌀ 10mm / ⌀ 25/64”) masonry drill bit For walls with wooden studs: 50mm / 2” (⌀ 5mm / ⌀ 13/64”) wood drill bit Pencil Take care of your safety Who cares about looking cool? Always wear personal protective equipment: Eye protection Ear protection Safety shoes...
- Page 5 2. Remove the thumbnut and detach the wall mount Ⓐ from the interface. Keep the thumbnut for later use. 3. Check the mounting holes on the TV screen. Adjust the dimensions of the interface accordingly, after loosening the pre-attached bolts with the Allen key. 4.
- Page 6 Are you missing any bolts? Or need different ones? The friendly team at Vogel’s Consumer Care are waiting to help: vogels.com/contact (http://www.vogels.com/contact) Make sure bolts and spacers are positioned correctly. Refer to the user manual of your TV for the correct mounting material. Step 2: Attach the wall mount to the wall How well do you know your walls? What they’re made of matters more than you think…...
- Page 7 70mm / 2.8” (⌀ 10mm / ⌀ 25/64”) masonry drill bit The contents of the wall mounting kit Ⓗ Ⓘ Ⓙ Spirit level Pencil 1. Determine where to mount your TV screen. Use the drilling template Ⓩ to mark the correct position on the wall if you’re using the TVA 7000 cable column or if the connecting cables protrude from the wall.
- Page 8 How deep do you drill? Check if the entire screw (except its head) fits in the hole before placing the plugs. This stops things from breaking. Vacuum the hole after drilling. The cable hole should only be used to lead cables that come out of the wall through the wall mount.
- Page 9 5. Slide the upper wall plate cover Ⓚ onto the wall mount Ⓐ. To remove the cover plate, press the left tab and slide it off the wall mount. Wall with wooden studs If you are mounting your TV screen onto a concrete/brick wall, please follow the instructions in the Solid concrete/Brick wall section.
- Page 10 Don’t just guess! The wall mount must always be attached to the studs. Always use a stud finder to determine the position of studs. Don’t destroy your belongings! 1. Determine where to hang your TV screen. Use the drilling template Ⓩ to mark the correct position on the wall if you’re using the TVA 7000 cable column or if the connecting cables protrude from the wall.
- Page 11 3. Attach the wall mount to the wall while making sure to: a. begin with the hole directly above the Vogel’s logo on the wall mount Ⓐ b. use the spirit level to level the wall mount c. attach the wall mount Ⓐ to the wall with the provided screws Ⓗ and washers Ⓙ Lubricate the screws for easy screwing in.
- Page 12 4. Slide the upper wall plate cover Ⓚ onto the wall mount Ⓐ. To remove the cover plate, press the left tab and slide it off the wall mount. Other wall type / I don’t know my wall type If your wall is a little special – for example, hollow bricks, metal stud walls, wood panels or plasterboard –...
- Page 13 2. Secure the interface to the wall mount with the saved thumbnut from step 1.
- Page 14 3. Level the wall mount and the TV screen. Use a spirit level and the Allen key to correct the position. Tighten the thumbnut and the thumb bolt with the Allen key when finished. The wall mount and TV must be leveled vertically and horizontally before using the wall mount! Step 4: Attach the cables to the wall mount 1.
- Page 15 4. Connect the power cable and the other cables to the TV. Make sure all other cables are neatly stowed away by using the vertical cable clip strips on the interface. 5. Put the lower wall plate cover Ⓛ onto the wall mount and the interface cover Ⓨ onto the back of the interface.
- Page 16 6. Connect the TV power cable to the power outlet. 7. Your DesignMount is now ready to be used! Need a long HDMI cable? Or a Cable Cover to hide your wall cables? Visit us online and order the right accessories directly through our website (https://www.vogels.com/en- gb/c/tv-bracket-accessories).
-
Page 17: Troubleshooting
Solution Just ask Vogel’s Consumer Care to request a service kit, and we’ll send everything you need. Click here (http://www.vogels.com/contact) to contact Vogel's Consumer Care. Problem My wall screws have snapped! Cause You might not be drilling deep enough…... - Page 18 It can also be found on our YouTube channel: www.youtube.com/c/VogelsForSure (http://www.youtube.com/c/VogelsForSure) What if I need spare parts? If you require a spare part, please contact your local dealer or Vogel's. Click here (http://www.vogels.com/contact) to contact Vogel's Consumer Care. Where can I find the drilling template? The drilling template is printed on the inlay card in the box.
- Page 19 What is the maximum screen size and weight of the TV in combination with the tv wall mount? The maximum screen size is 77 inch (196 cm) and maximum weight is 35 kg (77 lbs). The Screen Protection System (SPS®) prevents your TV bumping onto the wall (up to 65 inch). Does this product have a tilt function? There is no tilt in this product.
- Page 20 If the product has not been installed or used in accordance with the instructions; If applicable, if the holes in the wall have not been properly drilled in accordance with the Vogel's installation instructions for the applicable wall type; If the product has been altered or repaired by someone other than Vogel’s;...
- Page 21 If the product is used for different equipment than is mentioned on or in the packaging. Do you have any other questions? Please make use of our contact form. Vogel’s Products BV - Hondsruglaan 93 - 5628 DB Eindhoven - The Netherlands Vogel’s Products BV 2024 ©...
