Home Styles 88 5168 80 Manual

Side chair (black & cottage oak)

Advertisement

Quick Links

88 5168 80
Side Chair
(Black & Cottage Oak)
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
PART LIST
A.
Seat
1 pc.
HARDWARE LIST
Small
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
B.
Leg
1 pc.
Key Wrench
1 pc.
Head Cap Bolt (long)
4 pcs.(+1 extra)
servicedesk@homestyles-furniture.com
C.
Leg
1 pc.
Head Cap Bolt (Short)
3 pcs.(+1 extra)
Head Cap Bolt
4 pcs.(+1 extra)
D.
Back Frame
1 pc
.
Flat Washer
11 pcs.(+1 extra)
Spring Washer
11 pcs.(+1 extra)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 88 5168 80 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Home Styles 88 5168 80

  • Page 1 11 pcs.(+1 extra) Hex Wrench 1 pc. Head Cap Bolt Spring Washer Head Cap Bolt (long) 4 pcs.(+1 extra) 4 pcs.(+1 extra) 11 pcs.(+1 extra) Tools required for assembly : Phillips screwdriver Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319 servicedesk@homestyles-furniture.com...
  • Page 2 Assembly Instructions IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. STEP 1 Attach Leg (B) and (C) to Seat (A) with Flat Washers ,Spring Washers and Head Cap Bolts.
