MAN#650185

Kit Includes:

Installation:

1. Remove the three screws that secure the tail light lens and remove the lens.
2. Remove the light bulb
3. Push and twist to remove the plastic wire socket from the back side of the housing.
4. Now is a good time to clean the lens and housing. If lenses are in bad shape a new set is
recommended.
5. Remove the lock nut and flat plastic back plate from the back of the new LED assembly.
6. Make sure that one wire is still going through each hole in the
aluminum spacer. Insert the new LED assembly through the hole
where the original bulb and connector were located. Use caution
when feeding the wires through to avoid damaging the wire
insulation.
7. Guide the wires through the larger hole in the plastic back plate and slide
the back plate onto the stud sticking out the back side of the housing.
Ensure wires are not pinched to avoid shorting!
8. Secure the plastic back plate from the back side of the tail light housing
with the supplied #6 lock nut.
9. Make sure the original lens gasket is in place and replace the tail light
lens. Tighten the screws down carefully.
INSTALLATION INSTRUCTIONS
LAT-NR210
LED Tail Lights for 1957 Chevy Car
MAN#650185
