V30 Plus GNSS System User Manual
2.1 Overall Appearance
The product appearance is divided into three parts, including the upper cover, bottom
cover and control panel.
Upper Cover
Bottom Cover
Control Panel
Figure 2-1-1 Front
2.1.1 Upper Cover
The product appearance is divided into three parts, including the upper cover, bottom
cover and control panel.
Anti-Wear Buffer
Figure 2-1-2 Upper Cover
Anti-wear Buffer: Wear prevention points can enable the host to avoid scratching.
5
