- Page 1 Вбудовувані посудомийні машини Heinner HDW- Обрати BI6005IE+ +: Інструкція користувача...
-
Page 2: Safety Instructions
III. SAFETY INSTRUCTIONS General Safety Warnings • Read these instructions carefully before using your appliance and keep this manual for future reference. Please check the packaging of your machine before installation and the outer surface of the machine once the packaging has been removed. Do not operate the machine if it appears damaged or if the packaging has been opened. - Page 3 • Place knives and other sharp objects in the cutlery basket in a blade-down position. • For the models with the automatic door-opening system - when the EnergySave option is active, the door will open at the end of a program. To prevent damage to your dishwasher, do not attempt to close the door for one minute after it has opened.
-
Page 4: Product Description
IV. PRODUCT DESCRIPTION 1. Upper basket with racks 2. Upper spray arm 3. Lower basket 4. Lower spray arm 5. Filters 6. Rating plate 7. Control panel 8. Detergent and rinse-aid dispenser 9. Cutlery basket 10. Salt dispenser 11. Upper basket track latch... - Page 5 Technical specifications 12 place settings Capacity Dimensions (mm) 820-870(mm) Height 598 (mm) Width 570 (mm) Depth Net weight 38kg Operating voltage / frequency 220-240V 50 Hz Total current (A) 10(A) Total power (W) 1900(W) Maximum: 1 (Mpa) Minimum: Water supply pressure...
-
Page 6: Installation
INSTALLATION Machine positioning • When positioning the machine, place it in an area where dishes can be easily loaded and unloaded. Do not put the machine in an area where the ambient temperature falls below 0°C. • Read all warnings located on the packaging before removing the packaging and positioning the machine. - Page 7 Drain hose Connect the water drain hose directly to water drain hole or to the sink outlet spigot. This connection should be minimum 50 cm and maximum 110 cm from flor plane. IMPORTANT: Items will not wash properly if a drain hose longer than 4 m is used.
-
Page 8: Before Using The Appliance
VI. BEFORE USING THE APPLIANCE Preparing your Dishwasher for first use • Check whether the electricity and supply water specifications match the values indicated in the installation instructions for the machine. • Remove all packaging materials inside the machine. - Page 9 Testing strip (it’s not provided in product package) The washing effectiveness of your machine depends on the softness of the tap water. For this reason, your machine is equipped with a system that reduces the hardness in mains water supply.
- Page 10 Recommended usage: If you want to obtain better results while using combined detergents, add salt and rinse aid into your machine and adjust the water hardness setting and the rinse aid setting to the lowest position. Solubility of the tablet detergents produced by different companies can vary depending on the temperature and time.
-
Page 11: Loading Your Dishwasher
VII. LOADING YOUR DISHWASHER For best results, follow these loading guidelines. We recommend that you place large items (pots, pans, lids, plates and bowls) which are heavily soiled in the lower basket. The upper basket is designed for delicate and lighter dishware such as glasses, coffee and tea cups and saucers. - Page 12 Alternative Basket Loads Lower Basket Top Basket Incorrect Loads Incorrect loading can cause poor washing and drying performance. Please follow the manufacturer's recommendations for a good performans result Unsuitable items for dishwashing • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials.
-
Page 13: Programme Table
VIII. PROGRAMME TABLE Intensive Super 50’ Quick 30’ Program Name: Prewash 65°C Standard program for Suitable for normally soiled normally Suitable for Suitable to Suitable for daily using soiled daily lightly soiled rinse dishes Type of Soil: heavily soiled... -
Page 14: Control Panel
IX. CONTROL PANEL On/Off button Program Selection Button Display Delay Button Half Load Button Half Load Led Salt Indicator Rinse Aid Indicator iii. On/Off Button 1.Switch the machine on by pressing On / Off button. When machine is on, "--" will be shown on the Display (3). - Page 15 NOTE: If you decide not to start the selected programme, please see the "Changing a Programme" and "Cancelling a Programme" sections. NOTE: When there is insufficient softening salt, the Salt Lack Warning Indicator (ii) will illuminate to indicate the salt chamber needs filling.
-
Page 16: Cleaning And Maintenance
CLEANING AND MAINTENANCE Cleaning your Dishwasher is important to maintain the machine’s service life. Oil and lime may build up in your Dishwasher over time. If this occurs: • Fill the detergent compartment but do not load any dishes. Select a programme which runs at high temperature and run the Dishwasher empty. - Page 17 Spray arms Make sure that the spray holes are not clogged and that no food waste is stuck to the spray arms. If there is any clogging, remove the spray arms and clean them under water. To remove the upper spray arm undo the nut holding it in position by turning it clockwise and pulling it downwards.
-
Page 18: Troubleshooting
XI. TROUBLESHOOTING FAULT POSSIBLE CAUSE TROUBLESHOOTING Your Dishwasher is not plugged in. Plug your Dishwasher in. Your Dishwasher is not switched on. Switch your Dishwasher on by pressing the On/Off button. Fuse blown. Check your indoor fuses. The programme does not start. - Page 19 FAULT POSSIBLE CAUSE TROUBLESHOOTING Use the correct amount of detergent, as instructed in the programme Not enough detergent used. table. Rinse aid dosage and/or water Increase rinse aid and/or water softener level. Whitish stains remains on dishes. softener setting set too low.
- Page 20 AUTOMATIC FAULT WARNINGS AND WHAT TO DO TROUBLE POSSIBLE FAULT WHAT TO DO CODE Make sure the water inlet tap is open and water is flowing. Separate the inlet hose from the tap and clean the filter of the hose.
-
Page 21: Practical Information
XII. PRACTICAL INFORMATION 1. When the machine isn’t in operation: • Disconnect the plug and close the tap. • Leave the door slightly open to prevent odour formation. 2. Select the dry option to remove water droplets. 3. Place dishes in the machine properly to achieve the best energy consumption, washing and drying performance. - Page 22 CUSTOMER CARE AND SERVICE Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model and Serial Number. The information can be found on the rating plate. Subject to change without notice.
