Q-Spot™ 575
USER MANUAL
th
CHAUVET, 3000 N 29
Ct, Hollywood, FL 33020 U.S.A
(800) 762-1084 – (954) 929-1115
FAX (954) 929-5560
www.chauvetlighting.com
2006-05-17/13:25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q-Spot 575 and is the answer not in the manual?

Questions and answers

Summary of Contents for Chauvet Q-Spot 575

  • Page 1 Q-Spot™ 575 USER MANUAL CHAUVET, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com 2006-05-17/13:25...
  • Page 2: Table Of Contents

    DMX C ....................................... 4 HANNEL UMMARY ........................................5 RODUCT VERVIEW SETUP ....................................6 LAMP ............................................. 6 Maximizing the life of your lamp..................................6 Lamp Installation ........................................ 6 ............................................7 OWER ........................................7 XCHANGING GOBOS ............................................7 OUNTING ............................................8 OUNTING OPERATING INSTRUCTIONS ............................
  • Page 3: Before You Begin

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing.
  • Page 4: Introduction

    Rotating gobos  - 6 interchangeable rotating plus open - 3 metal, 3 dichroic installed - Additional gobos: 1 dichroic & 4 metal - Rotating gobo wheel spin in both directions at variable speeds Motorized focus  Variable strobe/shutter ...
  • Page 5: Product Overview

    Toggles programming MODE DMX Out & In DMX-512 connectors functions Steps backward through menu DOWN Power AC input IEC 60320 C14 and fuse holder functions Steps forward through menu functions Confirms selected menu ENTER function Q-Spot 575 User Manual 2006-05-17/13:25...
  • Page 6: Setup

    You will need to install a lamp prior to the initial operation of the fixture. A HMI575 high intensity discharge lamp is included. Do not touch the envelope (glass area) of the bulb with bare hands. If this happens, clean the lamp with alcohol and wipe it with a lint free cloth before installation.
  • Page 7: Power

    Exchanging gobos 1. Press both tips of the gobo tension ring together and remove from aperture. 2. Push the gobo with your finger from the back side following the same direction that the tension ring was removed. Q-Spot™ 575 Gobo Wheel Gobo outside diameter: 31 mm Gobo Image diameter: 22.5 mm...
  • Page 8: Mounting

    It is important never to obstruct the fan or vents pathway.  The installation of the projector has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation.
  • Page 9: Operating Instructions

    NSTRUCTIONS Control Panel Please be aware that after 12 seconds of no control panel activity the LEDs in the display will turn off. Press any button to initialize. On the control panel you can set the DMX address, set the fixture to Master/Slave mode, reset the fixture and change fixture personality trait.
  • Page 10: Operating Modes

    In automatic mode the internal programs run at the chase time pre-recorded. It is your choice to enable each fixture to run in Stand Alone mode by activating either of the two functions below or to proceed to enable slave fixtures as described in the following section.
  • Page 11: Dmx-512 Addressing

    You can apply a pan and tilt Invert by following the settings in the table below.
  • Page 12: Appendix

    DMX fixtures are designed to receive data through a serial Daisy Chain. A Daisy Chain connection is where the DATA OUT of one fixture connects to the DATA IN of the next fixture. The order in which the fixtures are connected is not important and has no effect on how a controller communicates to each fixture.
  • Page 13: Dmx Values

    Fast > Slow Lamp on/off & Reset 000  127 No Function 128  139 Lamp on after 3 seconds when lamp is off Fixture reset when lamp is on 140  229 No Function 230  239 Lamp off after 3 seconds 240 ...
  • Page 14 090  099 Gobo 9 100  109 Open 110  119 Gobo Bounce: Gobo 1 (Slow > Fast) 120  129 Gobo Bounce: Gobo 2 (Slow > Fast) 130  139 Gobo Bounce: Gobo 3 (Slow > Fast) 140  149 Gobo Bounce: Gobo 4 (Slow >...
  • Page 15: Maintenance

    Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical surfaces until they are free of haze and lint. Do not to touch the lamp glass when cleaning fixture. Oil and dirt can cause damage and premature aging of the lamp.
  • Page 16: General Troubleshooting

    Light will not come on Some discharge lamps require a cooling off period before the  after power failure electronics in the fixture can kick start it again, wait 5 to 10 minutes before powering up Loss of signal Use only DMX cables ...
  • Page 17: Technical Specifications

    Main (230V) ..................... 20mm Glass 6.3A Fast Blow CONTROL & PROGRAMMING Data input ..................... locking 3-pin XLR male socket Data output ..................locking 3-pin XLR female socket Data pin configuration ................pin 1 shield, pin 2 (-), pin 3 (+) Protocols........................DMX-512 USITT DMX Channels (Q-SPOT575) ......................16 ORDERING INFORMATION Q-Spot™...
