Q-Spot 200™
USER MANUAL
th
Chauvet, 3000 N 29
Ct, Hollywood, FL 33020 U.S.A.
(800) 762-1084 – (954) 929-1115
FAX (954) 929-5560
www.chauvetlighting.com
Snapshot
OK on Dimmer
Outdoor OK
Sound Activated
DMX512
Master/Slave
Multitap
Transformer
Replaceable Fuse
User Serviceable
Duty Cycle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q-Spot 200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chauvet Q-Spot 200

  • Page 1 Q-Spot 200™ Chauvet, 3000 N 29 USER MANUAL Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com Snapshot OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave Multitap Transformer Replaceable Fuse User Serviceable Duty Cycle...
  • Page 2: Table Of Contents

    DMX P ... 23 RIMER ... 24 ENERAL AINTENANCE ... 24 ETURNS ROCEDURE ... 24 LAIMS ... 25 XPLODED ... 26 IMENSIONS ... 27 ECHNICAL PECIFICATIONS ... 27 HOTOMETRICS Q-Spot 200 User Manual ... 19 ... 20 9/5/2007 2:59 PM...
  • Page 3: Before You Begin

    1. B EFORE What is included 1 x Q-Spot 200™ 250W MSD Lamp 5 additional metal gobos Power Cord Warranty Card User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition.
  • Page 4: Contact Us

    Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Q-Spot 200 User Manual Chauvet Lighting...
  • Page 5: Introduction

    Ad d i t i o n a l F e a t u r e s • Automatic pan & tilt correction • User-selectable basic or advanced operating modes • Micro-stepping motors • LCD display • Display auto on/off • Thermal switch • Fan cooled Q-Spot 200 User Manual 9/5/2007 2:59 PM...
  • Page 6: Dmx Channel Summary

    Vector speed Color wheel Gobo wheel and gobo shake Gobo rotate Strobe Dimmer Automatic and reset Effect Prism Focus Q-Spot 200 User Manual DVANCED MODE UNCTION ASIC MODE Tilt Color wheel Gobo wheel and gobo shake Gobo rotate Strobe Dimmer...
  • Page 7: Product Overview

    Product Overview Head Base Voltage Select Switch (Internal) Power Switch Q-Spot 200 User Manual Control Panel IEC Power Connector & Fuse Holder DMX Output DMX Input Easy Controller Input (sold separately, release date TBA) Microphone 9/5/2007 2:59 PM...
  • Page 8: Setup

    Never turn off the power to the unit while the lamp is striking. Always wait 15 minutes after powering on the fixture before powering down. Turning off the lamp during striking may permanently damage the lamp. Q-Spot 200 User Manual ocket 9/5/2007 2:59 PM...
  • Page 9: Lamp Alignment How-To

    With a flat head screwdriver wedge the fuse holder out of its housing. Remove the damaged fuse from its holder and replace with exact same type fuse. Insert the fuse holder back in its place and reconnect power. Q-Spot 200 User Manual Lamp Alignment Screws The fuse is located inside this compartment.
  • Page 10: Replacing Gobos

    Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference.
  • Page 11: Dmx Data Cable

    3-PIN TO 5- PIN CON VE R SION CHAR T If you use a controller with a 5 Note! CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion: IN TO ONVERSION Conductor...
  • Page 12: Setting Up A Dmx Serial Data Link

    (male) 3 pin connector. 3. Then, proceed to connect from the output as stated above to the input of the following fixture and so on. CHAUVET Certified DMX Data Cables Order Code Description DMX1.5 DMX Cable 1.5m/4.9ft DMX4.5...
  • Page 13: Mounting

    Never mount in places where the fixture will be exposed to rain, high humidity, extreme temperature changes or restricted ventilation. Safety cable attachment points Clamp attachment point Q-Spot 200 User Manual Note! Clamp is sold separatel Clamp attachment point Hanging Clamp...
  • Page 14: Operating Instructions

    Use the <UP> and <DOWN> buttons to navigate the menu map and menu options. Press the <ENTER> button to access the menu function currently displayed or to enable a menu option. To return to the previous option or menu without changing the value, press the <MENU> button. Q-Spot 200 User Manual NSTRUCTIONS Function...
  • Page 15: Menu Map

    Normal select: Reverse 6-Tilt select: Normal select: Reverse 7-Color select: Step select: Linear 8-Channels select: Basic select: Advanced 9-Info Q-Spot 200 User Manual 1-Address select: 001 2-Reset select: No 2-Reset select: Yes 3-Operation select: DMX 3-Operation select: Auto1 4-Display...
  • Page 16: Menu Functions

    Press the <MENU> button. Scroll up or down until <7-Color> is displayed. Press <ENTER>. Press up or down until <select: Step> or <select: Linear> is displayed. “Step” snaps to colors, “Linear” allows split colors. Press <ENTER>. Q-Spot 200 User Manual 9/5/2007 2:59 PM...
  • Page 17: To Change The Channels Setting

    The unit will react to the low frequencies of music via the internal microphone in Sound Active mode, or the unit will auto change in Auto Mode. In Random mode, the unit will periodically change between auto and sound-active modes. Q-Spot 200 User Manual 9/5/2007 2:59 PM...
  • Page 18: Master/Slave Mode (Master Sound, Master Auto)

    DMX, please read the DMX Primer on page 23. Press the <MENU> button. Scroll up or down until <3-Operation> is displayed. Press <ENTER>. Press up or down until <select: DMX> is displayed. Press <ENTER>. Q-Spot 200 User Manual 9/5/2007 2:59 PM...
  • Page 19 DMX Channel Values in Advanced Mode HANNEL ALUE 255 Pan 255 Tilt 255 Fine pan 255 Fine tilt 255 Vector Speed: (Normal > Slow) Q-Spot 200 User Manual UNCTION Color Wheel White (Open) Orange Yellow Green Blue Magenta Pink Cyan Color scroll: Slow >...
  • Page 20: Dmx Channel Values In Basic Mode

    DMX Channel Values in Basic Mode HANNEL ALUE 255 Pan 255 Tilt Q-Spot 200 User Manual Reset No effect Sound Active 1 Sound Active 2 Random Effect No Effect Effect 1 Effect 2 Effect 3 Effect 4 Effect 5 Effect 6...
  • Page 21 Q-Spot 200 User Manual Shaking Gobo 1 Shaking Gobo 2 Shaking Gobo 3 Shaking Gobo 4 Shaking Gobo 5 Shaking Gobo 6 Shaking Gobo 7 Gobo scroll: Fast > Slow Gobo Rotation Stop Rotate CW slow Rotate CW (slow > fast)
  • Page 22: General Troubleshooting

    If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. Q-Spot 200 User Manual...
  • Page 23: Technical Support

    XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’)
  • Page 24: General Maintenance

    Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return.
  • Page 25: Exploded View

    Exploded View Q-Spot 200 User Manual 9/5/2007 2:59 PM...
  • Page 26: Dimensions

    Dimensions Q-Spot 200 User Manual 9/5/2007 2:59 PM...
  • Page 27: Technical Specifications

    Data output ... locking 3-pin XLR female socket Data pin configuration ...pin 1 shield, pin 2 (-), pin 3 (+) Protocols... DMX-512 USITT DMX Channels ...14/8 ORDERING INFORMATION Q-Spot 200 ... Q-Spot 200 WARRANTY INFORMATION Warranty ... 2-year limited warranty Photometrics 3700 Q-Spot 200 User Manual 4.85...
