- Page 1 DMX-680 USER MANUAL CHAUVET, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com 2006-10-10 18:04...
-
Page 2: Table Of Contents
UPPORT ©CHAUVET, 2006, All Rights Reserved Information and specifications in this User Manual are subject to change without notice. CHAUVET assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. DMX-680 User Manual ... 10... -
Page 3: Before You Begin
World Wide Web DMX-680 User Manual Save the carton and all packing If you should require sending any items back to CHAUVET, call CHAUVET for a Note: (RMA) Return Merchandise Authorization number. The factory will not allow any shipments without an RMA. -
Page 4: Important Safety Information
If you have any questions about how to operate the fixture safely, please contact CHAUVET. P r o t e c t i o n a g a i n s t E l e c t r i c S h o c k •... -
Page 5: Introduction
• Compact and lightweight • LED display menu with invert • Pan/tilt invert option • Micro-stepping motors • Thermal switch & fan cooled DMX Channel Summary Channel Function Auto-programs, Lamp ON/OFF Dimmer Color Gobo Vector Speed Tilt DMX-680 User Manual 2006-10-10 18:04... -
Page 6: Product Overview
Product Overview Focusing lens gun Green LED: DMX Signal Indicator DMX-680 User Manual Projector Head Yoke Arm Carrying Handles LED Control Panel Fuse Compartment Clamp brackets with ¼ turn locks DMX Input Power cable Introduction Rubber feet DMX Output 2006-10-10... -
Page 7: Setup
6. There is no lamp alignment since the lamp is already optimized inside a mirrored dichroic reflector. 7. Insert lamp socket plate back into the rear of the fixture and tighten screws to complete installation. DMX-680 User Manual International Screw Color Live... -
Page 8: Mounting
Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 9: Dmx Data Cable
3 - P i n t o 5 - P i n C o n ve r s i o n C h a r t Note! to 3 pin adapter. CHAUVET Model No: DMX5M. The chart below details a proper cable conversion:... -
Page 10: Setting Up Admx Serial Data Link
(male) 3 pin connector. 3. Then, proceed to connect from the output as stated above to the input of the following fixture and so on. CHAUVET Certified DMX Data Cables Order Code Description DMX1.5 DMX Cable 1.5m/4.9ft DMX4.5... -
Page 11: Operating Instructions
DMX Mode: Sets the fixture to accept and operate in DMX control mode DMX-680 User Manual The DMX-680 has four control or operating modes that must be defined in each fixture in order to work correctly under stand-alone, master-slave or manual DMX control. -
Page 12: Stand-Alone, Master-Slave (N-So, N-Sl, N-Au)
Four small LEDs dots will blink during the selection process. 3. Press the <Enter> button to accept the new start channel. The four small LED dots will cease to blink to confirm selection. DMX-680 User Manual Blinks during selection Operating Instructions... -
Page 13: User Configurations
Combined Pan & Tilt Reverse (r.-.P.t.) PTION EVEL EVEL Combined Settings DMX-680 User Manual ESCRIPTION Standard Pan Movement: Normal left to right Reverse Pan Movement: Inverted movement from right to left Standard Tilt Movement: Normal setting Reverse Tilt Movement: Inverted setting... -
Page 14: Service Functions
PTION ESCRIPTION Standard: Standard display orientation Reverse: Rotated display orientation Fixture reset (r.E.S.t.) This function will re-initialize the fixture by returning all motors to its startup positions or otherwise known as (home position). DMX-680 User Manual Operating Instructions 2006-10-10 18:04... -
Page 15: Appendix
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) Returns Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. -
Page 16: Dmx Channel Values
Clean with soft cloth using normal glass cleaning fluid. - Always dry the parts carefully. - Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days. DMX Channel Values HANNEL ALUE DMX-680 User Manual UNCTION Control/Operating Mode DMX Mode Stand-alone (automatic) -
Page 17: Menu Map
Menu Map DMX-680 User Manual DMX 512 addressing. Use Up/Down buttons to <> change DMX values between 001 and 512. Sets the fixture to operate under DMX-512 control. A Universal DMX controller is required. Assigns Master status to fixture for Master-Slave configuration. -
Page 18: Technical Specifications
ORDERING INFORMATION Intimidator Spot™...DMX-680 Technical Support Address: Service Dept. 3000 N 29th Ct, Hollywood, FL 33020 (U.S.A.) Support (Email): tech@chauvetlighting.com Telephone: (954) 929-1115 - (Press 4) Fax: (954) 929-5560 - (Attention: Service) Website: http://www.chauvetlighting.com DMX-680 User Manual Appendix 2006-10-10 18:04...
