Summary of Contents for Durr Dental Hygowipe
- Page 1 Hygowipe Hygowipe Plus Installation and Operating Instructions 9000-616-18/30 *9000-616-18/30*...
-
Page 3: Table Of Contents
(Hygowipe Plus) � � � � � � � � � � 16 4�1 Hygowipe � � � � � � � � � � � � � � � � � � � � � 7 9�5 Changing batteries � � � � � � � � � � � � � 17 4�2 Hygowipe Plus �... -
Page 4: Important Information
The signal word differentiates between different Important levels of danger: information DANGER High risk of danger of serious injury or death 1. Documentation WARNING Possible risk of danger of serious injury or death These Installation and Operating Instructions CAUTION Risk of danger of minor form an integral part of the unit�... -
Page 5: 1�2 Notes On Copyright
Instructions in an accessible place so that the the operator touching the appliance� operator has instant access to them� The Hygowipe Plus paper towel dispenser is 2.4 Qualified personnel designed to provide either dry paper towels or towels coated with disinfectant as selected Instructions for use hands free�... -
Page 6: Current
Dürr Dental cannot accept any liability for damage caused during transport by Hygowipe ..... 6011-50 the use of unsuitable packaging, this is Batteries (4) also valid during the warranty term�... -
Page 7: 3�3 Special Accessories
50 - 60 3.4 Disposable materials Battery type D, LR20, 1�5 V The following disposable materials are required Battery life-span ca� 6000 cycles when operating the Hygowipe and must be Fuse type IP20 reordered: Protection class Hygowipe paper rolls, disinfectant (see acces- Weight 3�0... -
Page 8: 4�4 Model Identification Plate
4.4 Model identification plate The model identification plate (1) can be found inside the unit on the rear housing panel� Order no� / model no� Serial-No� Observe accompanying documentation! Date of manufacture CE-labeling Dispose of corrrectly according to EU directive (2002/96/EG-WEEE)� 4.5 Declaration of conformity We hereby declare that the product described above conforms to all requirements as laid... -
Page 9: Function
Paper dispenser Paper roll Disinfectant bottle Battery compartment Supply hose Fuse box Knurled screw for paper length 5.1 Functional features Hygowipe - Paper towel dispenser (dry) Hygowipe Plus - Paper towel dispenser (dry and wet) - Moistening with disinfectant 2012/12... -
Page 10: 5�2 Paper Towel Dispenser
When the unit detects a hand in range of the The infrared sensor has thee functional modes: infrared sensor (7) or if the button (7) is pressed then the Hygowipe Plus will dispense a paper Touch free dispensing on request towel� The length of the paper towel to be The unit dispenses a paper towel when a hand issued can be set�... -
Page 11: Installation
• Drill four holes in the wall according to drill stencil plan� • Remove stencil� • Place the rawl plugs in the holes� • Open the cover to the Hygowipe Plus� • Secure the Hygowipe Plus using the screws� 6.2 Mounting the dispenser on the table stand... -
Page 12: Electrical Connection
7. Electrical Connection The Hygowipe can also be operated using a power unit or batteries� 7.1 Insert the batteries Four batteries (LR20, 1�5 V) are supplied with the dispenser� • Remove the cover to the battery compartment (see fig� 6)� • Place the batteriesn in the battery compart- ment (see fig�... -
Page 13: 8�3 Inserting Disinfectant Bottle
8.3 Inserting disinfectant bottle (Hygowipe Plus) When working with disinfectants wear protective gloves and protec- tive glasses (goggles). • Remove the top of the disinfectant bottle� • Place the bottle adapter onto the bottle� Ensure the hose is in the correct direction (see fig�... -
Page 14: 8�4 Setting Length Of Paper Towel
8.4 Setting length of paper towel Every time the unit is operated the same length of paper is issued as set� The length of the pa- per towel can be set at any required length be- tween ca� 0�15 m and ca� 0�45 m by turning the setting screw (16)�... -
Page 15: Instructions For Use
Danger of personal injury as tear off strip is sharp Do not insert fingers into paper dispensing area� 9.1 Set moisture level (Hygowipe Plus) The selector switch for moisture content (6) has three positions: No moisture (dry) Medium damp Extremely wet... -
Page 16: 9�3 Change Paper Roll
The paper towel will automatically be taken up� • Tear off the paper issued� • Close the unit� • Set moisture level� 9.4 Changing the disinfectant bottle (Hygowipe Plus) ATTENTION Damage to unit by using incorrect fluid Evaporation deposits can lead to blockage of the moistening nozzles�... -
Page 17: 9�5 Changing Batteries
• Connect the hose of the bottle adapter to the supply hose (14)� Ensure that the coupling piece is clearly heard to lock (click) into place� • Close the cover� • Switch on at the main power switch� • Select moisture level II at the setting switch (6)� • Press button (7) until the paper towel dis- pensed has the required moisture level evenly over the surface�... -
Page 18: Cleaning
Service Team� 11.1 Clean the spray tubes (Hygowipe Plus) Blockage of one or more moistening nozzles can be caused by particles of dirt or deposits� In this event it is possible to rinse the spray tubes�... -
Page 19: 11�2 Replacing Fuse
11.2 Replacing fuse The following is required: - Fuse 230, T 1�6 AL, 5x20 (according to IEC / EN 60127-2) • Remove two screws to the fuse box (15)� • Open the fuse box� • Replace the fuse on the PCB (main board)� • Close the fuse box� 2012/12... -
Page 20: Trouble-Shooting
Trouble-shooting 12. Tips for Operators and Technicians Any repairs above and beyond routine maintenance must be carried out by suitably qualified personnel or one of our service technicians. Before beginning trouble-shooting unplug at the mains and remove all power and remove the batteries. - Page 21 2012/12...
- Page 22 2012/12...
- Page 23 2012/12...
- Page 24 DÜRR DENTAL SE Höpfigheimer Str. 17 74321 Bietigheim-Bissingen Germany Fon: +49 7142 705-0 www.duerrdental.com info@duerrdental.com...
