QUICK PIVOT FOR SHOREWAY
ASSEMBLY INSTRUCTIONS
HARDWARE KIT P/N 510-05603-00 - 510-05610-00
INSTRUCTION P/N: 610-05610-00
I I I I S S S S S S S S U U U U E E E E D D D D : : : : 1/4/24
TOOLS REQUIRED
- 9/16" SOCKET
- 9/16" WRENCH
- TORQUE WRENCH
SHEET 1 OF 4
c
Floe International, Inc.
48473 State Hwy. 65
McGregor, MN 55760
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Floe 510-05603-00
Summary of Contents for Floe 510-05603-00
- Page 1 QUICK PIVOT FOR SHOREWAY ASSEMBLY INSTRUCTIONS HARDWARE KIT P/N 510-05603-00 - 510-05610-00 TOOLS REQUIRED - 9/16" SOCKET - 9/16" WRENCH - TORQUE WRENCH Floe International, Inc. 48473 State Hwy. 65 INSTRUCTION P/N: 610-05610-00 McGregor, MN 55760 I I I I S S S S S S S S U U U U E E E E D D D D : : : : 1/4/24...
- Page 2 PARTS LIST/EXPLODED VIEW ITEM PART NUMBER DESCRIPTION SHOREWAY DOCK PIN, QUICK RELEASE W/RING GRIP 2-3/4" LONG 001-26729-00 001-70113-00 HHCS 3/8-16 x 2 1/2" SS 001-71017-00 FLAT WASHER 3/8", SS 001-76349-00 NUT 3/8", ALUMINUM 002-02083-00 PIVOT, QUICK DETAIL A SHEET 2 OF 4...
- Page 3 STEP 1 - INSTALL QUICK PIVOT ON THE END OF THE DOCK WITHOUT SUPPORT. (EXAMPLE: IF THE DOCK SECTION THAT THE SHOREWAY IS CONNECTING TO HAS A WHEEL KIT ON THE END WHERE THE ATTACHING SHOREWAY IS TO BE, BOLT QUICK PIVOT TO SHOREWAY.) PLACE QUICK PIVOT AS CLOSE TO THE OUTSIDE OF THE DOCK AS POSSIBLE...
- Page 4 S S S S T T T T E E E E P P P P 3 3 3 3 - SHOWN WITH SHOREWAY ANGLED DOWN (FIG. 3A AND 3B.) SHOWN UP (FIG. 3C AND 3D). - SHOWN WITH SHORE END WHEEL KIT ON DOCK SECTION, IF SUPPORTS ARE ON SHOREWAY, REVERSE QUICK PIVOT.
