FLOE QUICK ATTACH ROLL IN
X-SHALLOW WHEEL KIT
ASSEMBLY INSTRUCTIONS AND OWNERS MANUAL
4', 5', 6' & 8' WIDE DOCK SECTIONS
KIT P/N 510-27100-00, 510-27110-00
*DOCK NOT INCLUDED
NEVER ADJUST YOUR DOCK LEGS WITH
AN IMPACT WRENCH. NEVER ADJUST
YOUR DOCK LEGS WITH MORE THAN 15
FT-LBS OF FORCE. APPLYING TOO MUCH
FORCE TO YOUR DOCK LEGS WILL
DAMAGE THE MECHANISM.
INSTRUCTION P/N: 610-27100-00
RELEASED 10/3/22
FOR USE IN APPROXIMATELY 0"-13"
WE RECOMMEND THAT THE LOWER
DOCK FRAME IS A MINIMUM OF 8"
PROPERLY ADJUSTED. HOWEVER, IF
SHEET 1 OF 16
NOTE:
OF WATER.
ABOVE THE WATER WHEN
YOU HAVE HIGH WAVE
CONDITIONS THAT COMMONLY
EXCEED 15", WE RECOMMEND
THAT YOU RAISE YOUR DOCK
ACCORDINGLY.
TOOLS REQUIRED
-9/16" SOCKET/WRENCH
-3/4" SOCKET/WRENCH
-CORDLESS DRILL WITH SOCKET
ADAPTER & 1-1/8" SOCKET OR
FLOE SPEED WRENCH
-TORQUE WRENCH
-TAPE MEASURE
-LEVEL
-BLOCKING MATERIAL
© Manufactured by:
Floe International Inc.
48473 State Hwy. 65
McGregor, MN 55760
www.floeintl.com
Advertisement
Related Manuals for Floe 510-27100-00
Summary of Contents for Floe 510-27100-00
- Page 1 FLOE QUICK ATTACH ROLL IN X-SHALLOW WHEEL KIT ASSEMBLY INSTRUCTIONS AND OWNERS MANUAL 4’, 5’, 6’ & 8’ WIDE DOCK SECTIONS KIT P/N 510-27100-00, 510-27110-00 NOTE: FOR USE IN APPROXIMATELY 0”-13” OF WATER. WE RECOMMEND THAT THE LOWER DOCK FRAME IS A MINIMUM OF 8”...
-
Page 2: Leg Adjustment
LEG ADJUSTMENT NOTE: FOR USE IN APPROXIMATELY 0”-13” OF WATER. WE RECOMMEND THAT THE LOWER DOCK NEVER ADJUST YOUR DOCK LEGS WITH FRAME IS A MINIMUM OF 8” ABOVE THE WATER AN IMPACT WRENCH. NEVER ADJUST WHEN PROPERLY ADJUSTED. HOWEVER, IF YOU YOUR DOCK LEGS WITH MORE THAN 15 HAVE HIGH WAVE CONDITIONS THAT FT-LBS OF FORCE. - Page 3 BILL OF MATERIALS/EXPLODED VIEW 510-27100-00 WHEEL KIT, QA X-SHALLOW (PAIR) BZ NUMBER PART NUMBER QTY. DESCRIPTION FASTENERS, QA ROLL-IN SHALLOW W/K PAIR 001-02322-00 (&X-SHALLOW) 002-00291-00 QUICK CONNECT, QA ROLL-IN – 2” 007-00040-00 SPACER, POLYETHYLENE – 1.5” 110-01209-00 ASS’Y, W/K LEG (X-SHALLOW) BRONZE 001-02322-00 FASTENERS, QA ROLL-IN SHALLOW W/K PAIR (&...
- Page 4 BILL OF MATERIALS/EXPLODED VIEW 510-27110-00 WHEEL KIT, QA X-SHALLOW (SINGLE) BZ NUMBER PART NUMBER QTY. DESCRIPTION FASTENERS, QA ROLL-IN SHALLOW W/K SINGLE 001-02321-00 (& X-SHALLOW) 002-00291-00 QUICK CONNECT, QA ROLL-IN – 2” 007-00040-00 SPACER, POLYETHYLENE – 1.5” 110-01209-00 ASS’Y, W/K LEG (X-SHALLOW) BRONZE 001-02321-00 FASTENERS, QA ROLL-IN SHALLOW W/K SINGLE (&...
- Page 5 SUNDECK INSTALLATION 8’ WIDE SHOWN SHEET 5 OF 16...
- Page 6 STEP 1 TURN DOCK UPSIDE DOWN AND BLOCK CORNERS (OR USE A SOFT SURFACE) TO PROTECT THE DECK SURFACE (FIGURE 1.1). INSTALL (1) 1/2" X 1” BOLT AND (1) 1/2" NUT INTO EACH POCKET WELDED ON THE DOCK (FIGURE 1.2). NOTE: FIGURE 1.1 DIAGRAMS SHOW 4’...
- Page 7 INSERT WHEEL KIT LEGS INTO THE POCKETS THAT ARE WELDED ON THE DOCK (FIGURE 1.3). UNDER NORMAL CONDITIONS, THE WHEEL KITS ARE MOUNTED AS SHOWN IN FIGURE 1.4A. IF NECESSARY, WHEEL KITS MAY BE TURNED 180° FOR BOAT LIFT CLEARANCE. HOWEVER, SOME STABILITY MAY BE LOST (FIGURE 1.4B).
- Page 8 STEP 2 FIRST, SLIDE THE SPACERS ONTO THE WHEEL KIT SPINDLE. THEN, SLIDE THE WHEEL(S) (SOLD SEPARATELY) ONTO THE SPINDLE. LASTLY, PLACE A 2-1/2” WASHER ONTO THE SPINDLE (FIGURE 2.1). INSERT SPINDLE CLIP LEG INTO ONE OF THE HOLES IN THE SPINDLE, THEN PULL CLIP DOWN TO SNAP OTHER CLIP LEG INTO THE SECOND HOLE (FIGURE 2.2).
- Page 9 STEP 3 TURN DOCK RIGHT SIDE UP (FIGURE 3.1). ATTACH QUICK CONNECTS TO THE WHEEL KIT END OF THE DOCK SECTION IF ANOTHER SECTION IS TO BE CONNECT TO IT. TO ATTACH DOCK SECTIONS IN A STRAIGHT LINE, QUICK CONNECTS SHOULD BE ASSEMBLED AS SHOWN. SPACE THE QUICK CONNECTS AS FAR OUT AS POSSIBLE (FIGURE 3.2).
- Page 10 WHEN ANOTHER DOCK SECTION CONNECTS TO A SIDE OF THE DOCK, QUICK CONNECTS SHOULD BE PLACED AS SHOWN (FIGURE 3.3). ATTACH USING A 3/8” X 1” BOLT PER CONNECT (FIGURE 3.4). FIGURE 3.3 FIGURE 3.4 SHEET 10 OF 16...
- Page 11 TORQUE BOLTS TO 6 FT-LBS (FIGURE 3.5). QUICK CONNECTS SHOULD BE SPREAD APART AS FAR AS POSSIBLE TO KEEP THE JOINING SECTION FROM SHIFTING SIDEWAYS. PLACE CONNECTING DOCK SECTIONS IN THE QUICK CONNECT INSTALLATION/REMOVAL POSITION WHEN INSTALLING OR REMOVING MULTIPLE SECTIONS. PUSH THE DOCKS INTO POSITION IN THE WATER. ONCE THE DOCKS ARE IN POSITION, PUT THEM IN THE QUICK CONNECTS SET POSITION (FIGURE 3.6).
- Page 12 WITH THE CAPS REMOVED FROM THE DOCK, USE A FLOE SPEED WRENCH OR 1-1/8” SOCKET AND CORDLESS DRILL, ADJUST THE HEIGHT OF THE DOCK SO THE BOTTOM FRAME OF THE DOCK IS APPROXIMATELY 8” ABOVE THE WATER. *SEE NOTE ON SHEET 1. TURN THE DOCK ADJUSTING NUT ON THE TOP OF THE DOCK CLOCKWISE TO LOWER THE DOCK AND COUNTERCLOCKWISE TO RAISE THE DOCK.
- Page 13 NOTES SHEET 13 OF 16...
- Page 14 New Warranty Guidelines - Effective September 1, 2004 Two-Year Parts and Labor Warranty FLOE INTERNATIONAL, INC. will repair or replace, at their option, any portion of the dock system which fails as a result of a defect in material or workmanship during the first two years after the date of purchase. Items purchased by FLOE INTERNATIONAL, INC. are warranted by the original manufacturer and warranty is extended only to the original retail purchaser.
- Page 15 FLOE or an authorized FLOE dealership, with the exception of claims covered by the two-year parts and labor warranty that provides service up to 15 miles from the dealer. FLOE INTERNATIONAL reserves the right to inspect and perform rework at its main facility (F.O.B.) McGregor, Minnesota. Specifications may change without notice or obligation.
-
Page 16: Warranty Registration
Instantly register your FLOE products online! www.floeintl.com/registration WARRANTY REGISTRATION NOTE: FLOE products must be registered within 15 days of purchase to validate warranty. Please photocopy and fill out the form below and place in an envelope with proper postage or quickly register online. Please complete all information requested. FLOE INTERNATIONAL, INC. is not responsible for lost, stolen or misplaced warranty registrations. If you are mailing in your registration please address it to: FLOE International Inc., Warranty Registration Dept. 48473 State Hwy 65, McGregor, MN 55760-9514 NAME: _________________________________________________________________ PHONE: ______ / _______________ ADDRESS: ____________________________________________CITY: __________________ STATE: __________ ZIP: ________ DATE PURCHASED: ________/ ________/ ________ DEALER PURCHASED FROM: _______________________________________ E-mail: _____________________________________________ Yes please No you cannot contact me via e-mail with great offers and special promotions from FLOE International and it’s quality authorized dealers. PRODUCT PURCHASED Please check all that apply FLOE TRAILER......Size: _________ Model: __________ V IN#:__________________________________ ...
