*DOCK NOT INCLUDED
THESE HAND RAILS ARE INTENDED TO ASSIST IN MAINTAINING STABILITY WHILE WALKING
ON THE DOCK SECTION. THE HAND RAILS ARE NOT A SAFETY GUARD RAIL AND ARE NOT
INTENDED FOR PREVENTING CHILDREN AND ADULTS FROM FALLING IN THE WATER.
1
For more information, go to the owner support tab on the FLOE website
TOOLS REQUIRED
•9/16" SOCKET/WRENCH
ASSEMBLY INSTRUCTIONS
STABILIZING HAND RAIL
FLOATING DOCKS
4' HAND RAIL
5' HAND RAIL
6' HAND RAIL
8' HAND RAIL
10' HAND RAIL P/N 510-89310-00
12' HAND RAIL P/N 510-89312-00
16' HAND RAIL P/N 510-89316-00
WARNING!
•TORQUE WRENCH
• TAPE MEASURE
P/N 510-89304-00
P/N 510-89305-00
P/N 510-89306-00
P/N 510-89308-00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Floe 510-89304-00
Summary of Contents for Floe 510-89304-00
- Page 1 10’ HAND RAIL P/N 510-89310-00 12’ HAND RAIL P/N 510-89312-00 16’ HAND RAIL P/N 510-89316-00 For more information, go to the owner support tab on the FLOE website *DOCK NOT INCLUDED WARNING! THESE HAND RAILS ARE INTENDED TO ASSIST IN MAINTAINING STABILITY WHILE WALKING ON THE DOCK SECTION.
- Page 2 CAP, GREY 1.25” X 1.75” X 3” W/ HOLE *THERE MAY BE EXTRA HARDWARE, DEPENDING ON THE SIZE OF HAND RAIL YOU HAVE NUMBER KIT NUMBER PART NUMBER QTY. DESCRIPTION 510-89304-00 110-00531-00 ASS’Y, STD. SCTN’L/FLT. DOCK HAND RAIL-4’ 110-00530-00 WELD’T, STD. SCTN’L/FLT. DOCK HAND RAIL-4’...
- Page 3 EXPLODED VIEW (16’ HAND RAIL IS SHOWN)
- Page 4 ASSEMBLY (16’ HAND RAIL IS SHOWN) PLACE A WASHER ONTO EACH BOLT, THEN PLACE THEM INTO THE TRACKS ON THE SIDE OF THE DOCK. MATCH THE AMOUNT OF BOLTS AND WASHERS REQUIRED TO THE NUMBER OF MOUNT- ING HOLES ON THE HAND RAIL (4 PER BRACKET) (FIGURE 1.1). SLIDE THE BOLTS AND WASHERS INTO THEIR APPROXIMATE LOCATION ON THE DOCK SIDE (FIGURE 1.2).
- Page 5 POSITION THE HAND RAIL ON THE DOCK SIDE SO THAT THERE IS AN EQUAL DISTANCE ON BOTH ENDS OF THE DOCK BETWEEN THE END OF THE DOCK TO THE BRACKET (FIGURE 1.3). PLACE THE HAND RAIL ONTO THE BOLTS BY ALIGNING THE HOLES ON THE MOUNTING BRACKETS (FIGURE 1.4).
- Page 6 PLACE A 3/8” NYLOCK NUT ONTO EACH BOLT (FIGURE 1.5). TORQUE ALL NUTS TO 30 FT-LB (FIGURE 1.6). FIGURE 1.5 FIGURE 1.6...
- Page 7 NOTES...
- Page 8 FLOE INTERNATIONAL, INC. 48473 STATE HIGHWAY 65 • McGREGOR, MN 55760 www.fl oeintl.com All material copyright © 2022 FLOE International, Inc. Specifi cations subject to change without notice. P/N 610-89300-00 11/01/22...
