FLOE STANDARD ROLL-IN
LEG CONVERSION KIT
(FOR MOUNTING QUICK ATTACH ROLL-IN LEGS
ON STANDARD ROLL-IN DOCKS)
ASSEMBLY INSTRUCTIONS
* DOCK, LEGS, & WHEELS NOT INCLUDED
REFER TO THE INSTRUCTIONS
INCLUDED WITH THE WHEEL KIT
NEVER ADJUST YOUR DOCK LEGS WITH
AN IMPACT WRENCH. NEVER ADJUST
YOUR DOCK LEGS WITH MORE THAN 15
FT-LBS OF FORCE. APPLYING TOO MUCH
FORCE TO YOUR DOCK LEGS WILL
DAMAGE THE MECHANISM.
INSTRUCTION P/N: 610-17700-00
RELEASED 6/30/22
NOTE:
SHEET 1 OF 12
TOOLS REQUIRED
-(2) 9/16" SOCKETS/WRENCHES
-TAPE MEASURE
-TORQUE WRENCH
REFER TO WHEEL KIT INSTRUCTIONS
FOR ADDITIONAL TOOLS REQUIRED
© Manufactured by:
Floe International Inc.
48473 State Hwy. 65
McGregor, MN 55760
www.floeintl.com
Advertisement
Related Manuals for Floe 510-17700-00
Summary of Contents for Floe 510-17700-00
- Page 1 FLOE STANDARD ROLL-IN LEG CONVERSION KIT (FOR MOUNTING QUICK ATTACH ROLL-IN LEGS ON STANDARD ROLL-IN DOCKS) ASSEMBLY INSTRUCTIONS * DOCK, LEGS, & WHEELS NOT INCLUDED NOTE: REFER TO THE INSTRUCTIONS INCLUDED WITH THE WHEEL KIT TOOLS REQUIRED -(2) 9/16” SOCKETS/WRENCHES...
- Page 2 BILL OF MATERIALS/EXPLODED VIEW P/N 510-17700-00 KIT, STD. ROLL-IN LEG CONVERSION PART NUMBER DESCRIPTION 001-17700-00 FASTENERS, STD. ROLL-IN LEG CONVERSION KIT 001-70113-00 HHCS, 3/8-16 X 2-1/2” 18-8 SS 001-70119-00 HHCS, 3/8-16 X 4” 18-8 SS 001-71017-00 FLAT WASHER, 3/8” SAE SS 18-8 001-73818-00 BHCS, 3/8-16 X 1-3/4”...
- Page 3 ASSEMBLY NOTE: MEDIUM WHEEL KIT LEGS ARE SHOWN. REFER TO INSTRUCTIONS INCLUDED WITH THE WHEEL KIT. TURN DOCK UPSIDE DOWN AND BLOCK CORNERS (OR USE A SOFT SURFACE) TO PROTECT THE DECK SURFACE (FIGURE 1.1). SLIDE THE WHEEL KIT BRACKETS ONTO THE WHEEL KIT LEGS (FIGURE 1.2) (INCLUDED WITH WHEEL KIT).
- Page 4 INSERT WHEEL KIT LEGS INTO THE BRACKETS THAT ARE INSTALLED ON THE DOCK (FIGURE 1.3). CLAMP THE BRACKETS TO THE LEGS USING (1) 3/8” X 4” BOLT, (2) 3/8” WASHERS, AND (1) 3/8” NUT PER BRACKET. DO NOT TIGHTEN UNTIL BOLT LEGS ARE ASSEMBLED AND ALL BOLTS ARE INSTALLED (FIGURE 1.4).
- Page 5 NOTE: MEDIUM WHEEL KIT LEG IS SHOWN. REFER TO THE INSTRUCTIONS INCLUDED WITH THE WHEEL KIT. ATTACH THE 26” CENTER BRACES TO THE WHEEL KIT BRACKET WITH (1) 3/8” X 5” BOLT, (2) 3/8” WASHERS, AND (1) 3/8” NUT PER BRACE (FIGURE 1.5) (INCLUDED WITH WHEEL KIT HARDWARE).
- Page 6 ATTACH THE 26” SIDE BRACES TO THE SIDE BRACE BRACKET USING (1) 3/8” X 1-3/4” BOLT, (2) 3/8” WASHERS, AND (1) 3/8” NUT PER BRACKET. ATTACH THE SIDE BRACE BRACKET TO THE DOCK USING (1) 3/8” X 1-3/4” BUTTON HEAD BOLT, (1) 3/8” WASHER, AND (1) 3/8” NUT PER BRACKET (FIGURE 1.7) *FOR X-DEEP &...
- Page 7 REFER TO THE WHEEL KIT INSTRUCTIONS FOR ADJUSTING THE INNER LEG (SHALLOW & MEDIUM WHEEL KITS). SQUARE THE WHEEL KIT LEGS WITH THE DOCK. TIGHTEN ALL NUTS TO THE TORQUE SPECIFICATIONS SHOWN (FIGURE 1.9). SLIDE WHEEL(S) (SOLD SEPARATELY) ONTO THE SPINDLE ON THE WHEEL KIT AND PLACE A 2-1/2”...
- Page 8 INSERT SPINDLE CLIP LEG INTO ONE OF THE HOLES IN THE SPINDLE, THEN PULL CLIP DOWN TO SNAP OTHER CLIP LEG INTO THE SECOND HOLE (FIGURE 1.11). TURN THE DOCK RIGHT SIDE UP (FIGURE 1.12). FIGURE 1.11 FIGURE 1.12 SHEET 8 OF 12...
- Page 9 TO ATTACH DOCK SECTIONS IN A STRAIGHT LINE, ATTACH THE QUICK CONNECT TO THE DOCK (FIGURE 1.13) WITH (1) 3/8” X 2-1/2” BOLT, (1) 3/8” WASHER, AND (1) 3/8” NUT PER CONNECT (FIGURE 1.14). WITH THE CONNECTS SPREAD AS FAR APART AS POSSIBLE TO KEEP THE JOINING SECTION FROM SHIFTING SIDEWAYS, TORQUE NUTS TO 30 FT-LB (FIGURE 1.15).
- Page 10 WHEN ANOTHER DOCK SECTION CONNECTS TO A SIDE OF THE DOCK, QUICK CONNECTS SHOULD BE PLACED AS SHOWN (FIGURE 1.16). PLACE CONNECTING DOCK SECTIONS IN THE QUICK CONNECT INSTALLATION/REMOVAL POSITION WHEN INSTALLING OR REMOVING MULTIPLE SECTIONS. PUSH THE DOCKS INTO POSITION IN THE WATER. ONCE THE DOCKS ARE IN POSITION, PUT THEM IN THE QUICK CONNECT’S SET POSITION (FIGURE 1.17).
- Page 11 WITH THE CAP REMOVED FROM THE DOCK, USING A FLOE SPEED WRENCH OR 1-1/8” SOCKET AND CORDLESS DRILL, ADJUST THE HEIGHT OF THE DOCK SO THE BOTTOM FRAME OF THE DOCK IS APPROXIMATELY 8” ABOVE THE WATER. TURN THE DOCK ADJUSTING NUT ON THE TOP OF THE DOCK CLOCKWISE TO LOWER AND COUNTERCLOCKWISE TO RAISE.
- Page 12 WARNINGS NEVER ADJUST YOUR DOCK LEGS WITH AN CORDLESS DRILL MAY COME TO A IMPACT WRENCH. IF YOU CAN NOT TURN SUDDEN STOP WHEN THE LEG IS THE ADJUSTING NUT, DO NOT FORCE IT – FULLY EXTENDED OR RETRACTED. YOU HAVE REACHED THE END OF THE BE SURE TO HAVE YOUR ADJUSTMENT RANGE.
