GV-SD2322-IR
GV-SD3732-IR
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
www.a1securitycameras.com email: sales@a1securitycameras.com
Quick Start Guide
Available from A1 Security Cameras
GV-IP Speed Dome
ISD3732IR-QG-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-SD2322-IR and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-SD2322-IR

Summary of Contents for GeoVision GV-SD2322-IR

  • Page 1 Quick Start Guide GV-IP Speed Dome GV-SD2322-IR GV-SD3732-IR Before attempting to connect or operate this product, ISD3732IR-QG-A please read these instructions carefully and save this manual for future use. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    Contents Note for Connecting to GV-VMS / DVR / NVR........ii Note for Recording................iii Note for Installing Camera Outdoor............iv 1. Introduction ..................1 1.1 Packing List ......................1 1.2 Optional Accessories ..................... 2 1.3 Overview........................ 2 2. Installation ..................3 3. Connecting the Camera ..............6 4.

  • Page 4: Note For Connecting To Gv-Vms / Dvr / Nvr

    Note for Connecting to GV-VMS / DVR / NVR The GV-IP Speed Dome is designed to work with GV-VMS / DVR / NVR, a video management system. Note the following when the camera is connected to GV-VMS / DVR / NVR: 1.

  • Page 5: Note For Recording

    Note for Recording Mind the following when using a memory card for recording:  Recorded data on the memory card can be damaged or lost if the data are accessed while the camera is under physical shock, power interruption, memory card detachment or when the memory card reaches the end of its lifespan.

  • Page 6: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the camera outdoor, be sure that: 1. The camera is set up above the junction box to prevent water from entering the camera along the cables. Any power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 7: Introduction

    24V AC Power Adapter   M4 Hex Key Waterproof Rubber Set  Waterproof Requirements  GV-IP Speed Dome Software DVD (for GV-SD2322-IR)  GV-Software DVD (for GV-SD2322-IR)  Software Download Guide (for GV-SD3732-IR)  Warranty Card Available from A1 Security Cameras...

  • Page 8: Optional Accessories

    1.2 Optional Accessories Optional devices can expand the capabilities and versatility of your camera. Contact your dealer for more information. Name Details The GV-Mount Accessories provide a comprehensive lineup GV-Mount Accessories of accessories for installation on ceiling, wall and pole. For details, see GV-Mount Accessories Installation Guide on the software DVD.

  • Page 9: Installation

    Installation 2. Installation You can separately purchase optional mounting accessories to mount GV-SD2322-IR / 3732-IR on a wall, ceiling or pole. Make sure the wall has enough strength to support the camera and the mount. For details, see GV-Mount Accessories Installation Guide.
  • Page 10 Place the pendant tube on the wall, and mark the position of the screw holes. Drill holes on the wall, and secure the pendant tube to the wall with 4 self-prepared screws. Attach the safety lock of the camera to the pendant tube. Thread the data cable through the pendant tube.
  • Page 11 Installation Attach the camera to the pendant tube, rotate the camera until it is locked into position, and secure the indicated screws. Insert the pendant mount screws and tighten with the supplied M4 hex key. Thread the Ethernet cable through the waterproof rubber set as shown below. Note: The size of RJ-45 connector must be within 14 mm to go through the waterproof rubber set.

  • Page 12: Connecting The Camera

    3. Connecting the Camera The camera comes with a data cable that allows you to connect the camera to the power adapter, microphone, speaker, and I/O devices. Connect the supplied power adapter to the 3-pin terminal block. Either of the red or black cables can be used for anode (+) and the cathode (-).
  • Page 13 Connecting the Camera Wire Definition No. Wire Definition Brown Audio in Brown / White Green Audio out Green / White Gray Alarm IN 1 Purple Alarm IN 2 Black Orange Alarm In - Orange / White Alarm Out + Yellow RS-485 –...

  • Page 14: Accessing The Camera

    4. Accessing the Camera 4.1 System Requirements Once installed, your camera is accessible over the network. Make sure your PC has good network connection, and meet the following requirement: Intel Core i5-4670, 3.40 GHz Memory DDR3 8 GB RAM On Board Graphics Intel HD Graphics 4600 (Versions of driver from year 2014 or later required) Web Browsers...

  • Page 15: Looking Up The Dynamic Ip Address

    Note: The computer you use to configure the IP address must be under the same LAN with your camera. 1. Install the GV-IP Device Utility program included on the Software DVD (for GV-SD2322-IR) or download the program from http://www.geovision.com.tw/english/5_8.asp 2.
  • Page 16 4. The login page appears. 5. Type the default ID and password admin and click Apply to log in. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 17: Configuring The Ip Address

    Accessing the Camera 4.3 Configuring the IP Address If the camera is connected to LAN without a DHCP server, the default IP address will be 192.168.0.10. Follow the steps below to modify the IP address to avoid IP conflict with other GV-IP devices on the same LAN.

  • Page 18: The Web Interface

    5. The Web Interface Once you log in the Web interface, you will see the live view as shown below. For GV-SD2322-IR No. Name Function Set the display ratio of the image.  Scale: display images by 16:9. Proportional ...
  • Page 19 The Web Interface Adjust the audio output volume on the PC. Volume Adjust the microphone volume on the PC during audio Microphone communication between the PC and the camera. Snapshot Take a snapshot of the current image displayed on the PC. Local Recording Start or stop...
  • Page 20 Step 2: Click and hold the mouse button, and then drag from top down to specify an area. Then, the focus of the live view changes to the specified area. For more detailed functions, refer to For GV-SD2322-IR, 5. The Web Interface. Available from A1 Security Cameras www.a1securitycameras.com email: sales@a1securitycameras.com...

  • Page 21: Ptz Control Panel

    The Web Interface 5.1 PTZ Control Panel You can find the PTZ control panel to the right of the live view. No. Item Function 1 Auto Pan Start or stop auto panning of the camera. 2 PTZ Control Panel Control the direction of the camera and release the control. 3 PTZ Speed Adjust the moving speed of the PTZ camera.
  • Page 22 Adding a Preset Point 1. On the Live View page, click Preset on the control panel. 2. Adjust the camera until it points toward the desired direction. 3. Adjust zoom and focus as needed to obtain the optimal image. 4. Click the Add button to add it as a preset.
  • Page 23 The Web Interface Adding a Patrol Route 1. On the Live View page, click Patrol on the control panel. 2. Click the Add button to add a patrol route. 3. On the Add Patrol page, enter the route ID and name. 4.

  • Page 24: Upgrading System Firmware

    6. Upgrading System Firmware GeoVision periodically releases the updated firmware on the website. To load the new firmware into the camera, follow the instructions below. 1. At the top of the Web interface, click Setup. 2. In the left menu, select System and select Maintenance. This page appears.

  • Page 25: Restoring To Factory Default

    Restoring to Factory Default 7. Restoring to Factory Default You can restore the camera to factory default settings using the Web interface or directly on the camera. 7.1 Using the Web Interface To restore to default settings using the Web interface: 1.

  • Page 26: Directly On The Camera

    7.2 Directly on the Camera 1. Unscrew the back cover of the camera. 2. Press and hold the default button for about 30 seconds. 3. When the camera rotates twice, the process of loading default is completed and the camera robots automatically.
