SCREEN HR8-ZIP INTERIOR BO
1. LIST OF REQUIRED TOOLS
•
Ladder
•
Dril
•
Crosshead screwdrivers
•
Set of metal dril bits
•
Masonry dril bits (6 mm and 8 m)
•
Set of Allen keys
•
Pop rivet tool
•
Tape measure and pencil
•
Spirit level, plumb line and hose level
•
Voltmeter or test lamp 220 V
•
Test cable with switch
•
Silicon caulk or joint sealing strip
2. ASSEMBLY
2.1. CHECK THE PROVIDED PARTS
Check the provided parts and open the bag containing the fittings. Divide the screws, washers and caps equally between
the guide rails. You should have an equal amount of fastening material for each guide rail.
2.2. CHECK THE HEIGHT AND WIDTH
Measure the width of the screen box and the window opening, then determine whether the box is the right size for the
installation situation.
Also check the height from the top of the box to the bottom of the guide rails, including the end stops.
Measure the inside height of the window frame. Check whether they match, taking the mounting bracket into account.
Validity of the manual: 12.9.2022
MEASUREMENT AND ASSEMBLY MANUAL
1
