SCREEN HR7, HR8-ZIP
1. LIST OF REQUIRED TOOLS
•
Ladder
•
Dril
•
Crosshead screwdrivers
•
Set of metal dril bits
•
Masonry dril bits (6 mm and 8 m)
•
Set of Allen keys
•
Pop rivet tool
•
Tape measure and pencil
•
Spirit level, plumb line and hose level
•
Voltmeter or test lamp 220 V
•
Test cable with switch
•
Silicon caulk or joint sealing strip
2. ASSEMBLY
2.1. CHECK THE PROVIDED PARTS
Check the provided parts and open the bag containing the fittings. Divide the screws, plugs, washers and caps equally
between the guide rails. You should have an equal amount of fastening material for each guide rail.
2.2. CHECK THE HEIGHT AND WIDTH
Measure the width of the screen box and the window opening, then determine whether the box is the right size for the
installation situation.
Also check the height from the top of the box to the bottom of the guide rails, including the end stops.
Measure the inside height of the window frame. Check whether they match, taking the mounting bracket into account.
Validity of the manual: 1. 6. 2017
MEASUREMENT AND ASSEMBLY MANUAL
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Isotra SCREEN HR7, screen HR8-ZIP
Summary of Contents for Isotra SCREEN HR7, screen HR8-ZIP
- Page 1 MEASUREMENT AND ASSEMBLY MANUAL SCREEN HR7, HR8-ZIP 1. LIST OF REQUIRED TOOLS • Ladder • Dril • Crosshead screwdrivers • Set of metal dril bits • Masonry dril bits (6 mm and 8 m) • Set of Allen keys • Pop rivet tool •...
- Page 2 MEASUREMENT AND ASSEMBLY MANUAL HR7: HR8-ZIP: fig. 1 Final width B = the distance between the end brackets. Final height H = the height including box and guide rail ends (thickness = 2 mm) except the mounting bracket. Note: the final height H with steel cable from the top edge of the box to the lower side of the bottom rail. 2.3.
- Page 3 MEASUREMENT AND ASSEMBLY MANUAL 2.3.1. OPERATING EXITS FOR HANDLE fig. 2 rod 90° rod 90° rod 90° rod 90° exit A exit B exit O exit K 2.3.2. MOTOR EXITS fig. 3 Validity of the manual: 1. 6. 2017...
- Page 4 MEASUREMENT AND ASSEMBLY MANUAL 2.4. PRE-DRILLING THE GUIDE RAILS Guide Drilling on the Drilling in the Sealing Distance Clip mounting* End stop**** rail side back strips** support*** Validity of the manual: 1. 6. 2017...
- Page 5 MEASUREMENT AND ASSEMBLY MANUAL Validity of the manual: 1. 6. 2017...
- Page 6 MEASUREMENT AND ASSEMBLY MANUAL * Clip mounting These guide rails have two small L-shaped notches on the back. These are either used for clipping the guide rails to the window frame, using the provided clips, or they are fitted with sealing strips. The clips must be screwed on each side of the window frame in one straight and vertical line.
- Page 7 MEASUREMENT AND ASSEMBLY MANUAL 2.5.1. METHOD 1 – AFFIX THE BOX USING THE MOUNTING BRACKETS, THEN SLIDE THE GUIDE RAILS ONTO THE CONSOLE PIVOT AND SECURE THE GUIDE RAILS WITH SCREWS Step 1: Drilling holes for the mounting brackets Box type spirit level Place the mounting brackets against the mounting surface.
- Page 8 MEASUREMENT AND ASSEMBLY MANUAL Step 2: Installing the box on the mounting brackets One mounting bracket per console, as close as possible to the console. Any additional brackets are mounted in the middle of the box, evenly spaced across its width, and are intended to prevent wider boxes from sagging.
- Page 9 MEASUREMENT AND ASSEMBLY MANUAL fig. 11 fig. 10 fig. 13 fig. 12 Validity of the manual: 1. 6. 2017...
- Page 10 MEASUREMENT AND ASSEMBLY MANUAL – 2.5.2. METHOD 2 PLACE THE COMPLETE BOX / GUIDE RAIL ASSEMBLY IN OR AGAINST THE WINDOW OPENING AND SCREW THEM IN PLACE through hole chamber of guide rail for clips through hole chamber of guide rail fig.
- Page 11 MEASUREMENT AND ASSEMBLY MANUAL Step 2: Sliding the guide rails over the console pivots on the bottom of the box Place the screen box on the cardboard packaging (take care not to damage the paint finish). Next slide the pre-drilled guide rails onto the console pivots on each of the side consoles.
- Page 12 MEASUREMENT AND ASSEMBLY MANUAL fig. 21 fig. 20 Step 4: Attaching the box to the mounting brackets and screwing the guide rails in place (1) Push the box upwards into the mounting brackets. (2) Feed the motor cable through to the inside. Then push the box into the brackets so the slots in the back of the box engage with the L-profiles.
- Page 13 MEASUREMENT AND ASSEMBLY MANUAL 2.5.3. METHOD 3 – SCREWING THE GUIDE RAILS IN PLACE AND THEN PUSHING THE BOX ONTO THE GUIDE RAILS (ONLY FOR SCREENS WITHOUT MOUNTING BRACKETS through hole chamber of guide rail for clips through hole chamber of guide rail fig.
- Page 14 MEASUREMENT AND ASSEMBLY MANUAL Step 2: Mounting the guide rails Screw the guide rails to the mounting surface. Make sure the top of the guide rails are positioned at exactly the same height and are level. Step 3: Sliding the screen box onto the guide rails Lift the box and feed the motor cable to the inside.
- Page 15 MEASUREMENT AND ASSEMBLY MANUAL fig. 28 Make sure the box is always securely mounted. See section „Installation of controls“. 2.6. CHECKING FOR SQUARENESS Always make sure the screen is installed perfectly level and square. There is only one way to check and correct this. First check whether the box is mounted perfectly level.
- Page 16 MEASUREMENT AND ASSEMBLY MANUAL 3. GENERAL INFORMATION 3.1. CHECKING THE INSTALLATION The installation is checked by testing its functionality. The screen is lowered and raised again. This should proceed smoothly, and no creases should develop during lowering. 3.2. MOUNTING THE BOX This can be done in several ways: ...
- Page 17 MEASUREMENT AND ASSEMBLY MANUAL 4.2.1. WIRING DIAGRAM FOR A SINGLE POLE SWITCH The motor has 4 wires. Yellow/green (earth), blue (neutral), brown and black (up and down control). There should be three wires available from the protected mains circuit. Yellow/green (earth), blue (neutral) and phase wire. Connect the wires according to the diagram.
- Page 18 MEASUREMENT AND ASSEMBLY MANUAL Remark concerning the motor: If the motor is of the standard LT type, you can continue following the instructions in this manual. For the LS motor, the stop positions are not set with push buttons but rather with Allen key setting pins (consult the accompanying manual). If an Altus RTS type is used, consult the instructions that accompany the motor.
- Page 19 MEASUREMENT AND ASSEMBLY MANUAL voltages will burn out the switches inside the motor housing. Thus heed the following advice: Always use the relay boxes and switches supplied by us, to control two or more motors with a single switch. The same applies when using an wind/sun automatic controller. 4.2.
-
Page 20: Installation Options
MEASUREMENT AND ASSEMBLY MANUAL fig. 34 fig. 35 4.3. CRANK HANDLE OPERATION WITH EYE – FOR OUTDOOR OPERATION In this case, the screen box is fitted with a long, metal eye. A crank handle rod with a hook can be hooked onto this to operate the screen. - Page 21 MEASUREMENT AND ASSEMBLY MANUAL in order to mount the box more securely if you do not wish to use mounting brackets. Make sure the mounting screws cannot damage the fabric. to finish or seal the gap between the box and the wall. fig.
- Page 22 MEASUREMENT AND ASSEMBLY MANUAL 6.4. BOTTOM SLAT IS NOT HORIZONTAL WHEN IT REACHES THE TOP: The guide rails are parallel but not perpendicular to the box. First check whether the box is perfectly level, then measure along the diagonals and correct the installation. 6.5.
- Page 23 MEASUREMENT AND ASSEMBLY MANUAL • Remove the fabric roll from the retainer. • Remove the bottom slat from the guide rails (see illustration). • Detach the zipper and fabric from the sliding blocks. • Pull the bottom slat off of the fabric. •...
