@ VOLUME CONTROL [OFF/VOL]
Turns power ON and adjusts the audio level.
@ PTT SWITCH [PTT]
Push and hold to transmit; release to receive.
© UP/DOWN KEYS [AJ)IV]
e Push to select the operating channel.
¢Can be programmed as [ * ]/[#]. (SmarTrunk mode only)
@ DEALER-PROGRAMABLE KEYS
[POV[P1)/[P2V[P3V[AV[BVICVIDY [IM AH
Can each be programmed for one of
several functions by your Icom Dealer (see right).
@ KEYPAD
Used to enter DTMF codes, the operating channel, etc.
@ ANTENNA CONNECTOR
Connects the supplied antenna.
@[SP}/[MIC] JACK
Connect optional speaker-microphone.
© ACTIVITY LED
Lights red while transmiting.
© FUNCTION DISPLAY
Displays the following the information:
eCH number.
¢5-tone indication.
*Low-battery indication.
¢DTMF numbers.
e Low-power indication.
e Skip-ch indication.
e Audible indication.
Z NOTE: Above functions depend on presetting.
E General
"1: IC-F3/C-F4 only.
*2: IC-F3S/IC-F4S only.
*3: SmarTrunk || mode when assigned [ * |, #] functions only.
© Programmable key reference.
IC-F3/IC-F4
3
j |
