Danfoss AME 110 NL Operating Manual page 2

AME 110 NL/NLX
❹
DIP switches
DIP 1
DIP 4
12 sec/mm 3 sec/mm
d [mm] t [sec] d [mm]
2 24 2
4 48 4
8 96 8
❺
LED
4x LED
2 | © Danfoss | 2024.04
Reset
LED 1 LED 2 LED 3 LED 4
t [sec]
6
12
24
Calibration
Movement
Opening
Closing
Position
Closed 0%
Open 1-24%
Open 25-49%
Reset (button)
Under 1 second = Calibration
2 seconds = Turn OFF/ON LED indication
Alarm / Warning
Error during calibration
Missing control signal
Agenda LED color
ON
OFF
DIP 2
DIP 5
 
 
 
Open 50-74%
Open 75-99%
Open 100%
Press reset button, keep pressing until:
Click button 1 second
 
Calibration
 
 
 
Yellow
Green
DIP 3
DIP 6
   
   
   
2 second 3 second
   
OFF/ON LED
   
   
   
Red
