Note: By default, there is no password. To
increase security, when you log on, complete
the steps outlined in Creating a new CPT admin
password for a controller in EasyIO Hardening
Guide (LIT-12013986).
FS LED states
The following table displays the LEDs blink rate descriptions:
Table 2: FS LED states
LED LED color
label
PWR Green
ERR Red
STS Green
TXRX Yellow
Micro SD card insertion and removal
To insert the card, remove the cover first. For more
information about how to remove the cover, see
Removing the controller
card, press the card to release it from the slot. To find the
slot, see the following figure:
Figure 27: SD card and SD card slot
Table 4: Micro SD card specifications
Specification
Recommended tested brands
Capacity tested
Normal state State
On steady Off steady
On steady
Off steady Constant rapid blinks
On steady
Off steady
1 Hz blinks 1 Hz blinks
Off steady
1 Hz to 5 Hz 1 Hz to 5 Hz blinks
blinks
Off steady
cover. To remove the micro SD
What to do next:
For more information about CPT, Refer to EasyIO CPT User
Guide (LIT-12013978).
Description
No power
Power is supplied by primary voltage
Communication error between the FM-01
module and the base board
Firmware upgrade in process. Ensure no power
loss occurs during this period.
No errors
Normal operation
Controller fault
Normal data communication
No data transmission
Table 3: SD card and SD card slot
Callout
1
2
Micro SD card specifications
You can use a micro SD card with FS controllers for extra
backup storage. Use a micro SD card that meets the
following specifications:
Remark
Transend
Kingston
2 GB
4 GB
8 GB
16 GB
Component
Micro SD card slot
Micro SD card
