Summary of Contents for SEWOO LK-P41
- Page 1 MOBILE PRINTER MODEL : LK-P41 USER’S MANUAL Aroot Co., Ltd. 28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea TEL +82-31-8077-5000 / FAX +82-31-624-5310 / http://www.miniprinter.com All specifications are subject to change without notice P41 ENG Rev. I 11/2023...
- Page 2 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions. 1) This device may not cause harmful interference, and including 2) T his device must accept any interference received, interference that may cause undesired operation. Tim Kloeker 19700 S Vermont Ave Ste 200 Torrance, CA 90502 | USA NA_Sales@miniprinter.com...
-
Page 3: For Canada
For USA For Canada Information to user; This class B digital apparatus complies with Canadian ICES-003 Caution: The user that changes or modifications not expressly approved by the Aroot Co., Ltd., Cet appareil num rique de la class B est conforme la norme NMB-003 du Canada responsible for compliance could void the user’s authority to operate the equipment. -
Page 4: Table Of Contents
Table of Contents 1. Safety Precautions Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) identified in the badge, and has been certified by the developer 2. Unpacking to meet Apple performance standards. -
Page 5: Safety Precautions
1. Safety Precautions For better safety and reliability, adhere to the following precautionary measures. WARNING Read and follow the instructions carefully before operation of the product. Failure to follow these instructions could result in fire, electric shock, Indication other injuries, or property damage. Do not disassemble, Prohibition Must follow... -
Page 6: Unpacking
2. Unpacking 3. Product overview Standard Front Paper Feed Button Power switch Open Button Printer Battery Quick Manual SERIAL Charger USB Cable Serial Cable Bottom Roll Paper Optional DC Power Battery Battery Cradle Car Adapter Leather Case Shoulder Strap (Charging Cradle) -
Page 7: Usage And Installation
4. Usage and Installation 4-1. Control Panel Usage 4-2. Battery Installation Hook Button Name function - This button is used to turn the printer on and off. - When the printer is off, press this button for Power approximately 3 seconds and the printer will power Button on. -
Page 8: Charging Battery
4-3. Charging Battery 4-4. Charging Cradle Optional Lamp Lamp DC Jack 1 Make sure the printer is turned off. 1 Insert the battery into the battery charger as shown above. 2 After opening the DC JACK cover, connect the DC JACK to the printer. 2 Connect the DC JACK to the charging cradle. -
Page 9: Car Charger Usage (Optional)
4-5. Car Charger Usage 4-6. Paper Installation Optional Printer Press the PUSH button to open the Insert the paper in the correct direction. paper cover. See the image above. Battery holder Connect the car charger into the printer or battery cradle. Input 12 ~ 24V Output... -
Page 10: Leather Case Usage (Optional)
4-8. Self Test 4-7. Leather Case Usage Optional Turn off the power by pressing the While you are holding the FEED button, power button for approximately 3 press the power button. seconds. Open the leather case. Place the printer into the leather case. NOTE 01 To print ASCII pattern additionally, press the Feed button once more. -
Page 11: Cleaning The Printer
5. Cleaning the Printer Self-Test Printout Sample If the interior of the printer is dusty, printing quality can be reduced. In this case, follow the instructions below to clean the printer. Upon initial installation or for NOTE troubleshooting, you can run the diagnostic test to get information 01 Make sure to turn the printer power off prior to cleaning. -
Page 12: Peripheral Connection
6. Peripheral Connection 6-3. Interface Cable Connection This product can communicate with other devices via Bluetooth, Wi-Fi, or a communication cable. Serial 6-1. Bluetooth Connection Optional 1 The Printer can be connected to devices equipped with Bluetooth communication capabilities(PDAs, PCs, etc.). 2 Use the Bluetooth connection function supported by your device to connect to 1 Connect USB or Serial cable to the connector on the printer. -
Page 13: Printer Specification
7. Printer Specification Printing Method Paper Type Thermal Paper / Label Direct Thermal Printing Speed 80 mm/sec Width 50 mm ~ 112 mm Resolution 203 DPI Thickness 0.06 mm ~ 0.16 mm Paper Font A(12x24), Font B(9x17), Asian Font(KOR, Roll Max ESC/POS Max. -
Page 14: Cpcl Command Compatibility
8. CPCL Command Compatibility GRAPHICS Compatibility NOTE ○ Compatible Compatible with only Partially Not Compatible LINE ○ commanders provided Compatible INVERSE-LINE ○ by the manufacturer. PATTERN ○ ○ ● △ GRAPHICS ○ ○ Advanced Commands Compatibility Printer Commands Compatibility CONTRAST ○... -
Page 15: Utilities
This program is for label form design and designed LabelMaker(CPCL) label printing. Android Utility It is a utility app that prints text, barcodes, images, (Sewoo M_Utility) etc. through Bluetooth and Wi-Fi communication, (ESC/POS) and able to printer settings. -
Page 16: S/W
Mac Driver in the Mac OS environment. Android Plugin This is a print service plug-in that allows you to print (Sewoo Print Service documents, images, and web pages without installing Plugin) (ESC/POS) additional apps. This is library for communication and data output Windows SDK with Mobile printer in Windows OS.
