MOBILE PRINTER
MODEL : LK-P43Ⅱ
USER'S MANUAL / Peeler
Aroot Co., Ltd.
28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea
TEL +82-31-8077-5000 / FAX +82-31-624-5310 / http://www.miniprinter.com
All specifications are subject to change without notice
P43Ⅱ(Peeler) ENG Rev. 03/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK-P43II and is the answer not in the manual?

Questions and answers

Related Manuals for SEWOO LK-P43II

Summary of Contents for SEWOO LK-P43II

  • Page 1 MOBILE PRINTER MODEL : LK-P43Ⅱ USER’S MANUAL / Peeler Aroot Co., Ltd. 28-6, Gajangsaneopdong-ro, Osan-si, Gyeonggi-do ,18103, Republic of Korea TEL +82-31-8077-5000 / FAX +82-31-624-5310 / http://www.miniprinter.com All specifications are subject to change without notice P43Ⅱ(Peeler) ENG Rev. 03/2024...
  • Page 2 This device complies with part 15 of the FCC Rules. Use of the Made for Apple badge means that an accessory has been designed to Operation is subject to the following two conditions. connect specifically to the Apple product(s) identified in the badge, and has been certified by the developer to meet Apple performance standards.
  • Page 3 For USA For Canada Information to user; This class B digital apparatus complies with Canadian ICES-003 Caution: The user that changes or modifications not expressly approved by the  Cet appareil num rique de la class B est conforme la norme NMB-003 du Canada Aroot Co., Ltd., responsible for compliance could void the user’s authority to operate The antenna cannot be removed (and changed) by user.
  • Page 4 4 For Safety BATTERY SAFETY a. Do not disassemble battery. For better safe use, reliability and performance of the battery,  b. Do not use battery when something abnormal found such as smells, deformation, please review the following instructions carefully. discoloration, and so on.

  • Page 5: Table Of Contents

    Table of Contents 1. Safety Precautions 5. Peripheral Connection 2. Unpacking 5-1. Bluetooth Connection (Optional) 5-2. Wi-Fi Connection (Optional) 3. Product Overview 5-3. Interface Cable Connection 4. Setting Up the Product 6. Cleaning the Printer 4-1. Display 6-1. Print-Head Cleaning 4-2.

  • Page 6: Safety Precautions

    1. Safety Precautions For better safety and reliability, adhere to the following precautionary measures. WARNING Read and follow the instructions carefully before operation of the product. Failure to follow these instructions could result in fire, electric shock, Indication other injuries, or property damage. Do not disassemble, Prohibition Must follow...

  • Page 7: Unpacking

    2. Unpacking 3. Product overview Standard Front PEELER WING Cover Open Button Printer Battery Belt Clip AC Cord PEELER BODY Display Adaptor USB Cable Serial Cable Roll Paper SERIAL Bottom Quick Manual Shoulder Strap Ring Battery Optional Belt Clip Connector Charger Connector Battery Cradle Car Adapter...

  • Page 8: Setting Up The Product

    4. Setting Up the Product 4-1. Display 4-2. Installing the Battery Button Name function - Advances the paper, clears error messages, and moves down through menu options. Paper Feed/ 01 Refer to “4-13” for Diagnostic Test information. Down Button 02 Refer to the service manual regarding Hexadecimal Dumping.

  • Page 9: Removing The Battery

    4-3. Removing the Battery 4-4. Charging the Battery 1 Be sure the printer is turned off. 2 After opening the DC JACK cover, insert DC JACK into the printer. 3 Plug the power cord into the electrical outlet. Remove the battery as shown. The charge indicator LED Status charging...

  • Page 10: Battery Charger Usage (Optional)

    4-6. Car Charger Usage 4-5. Battery Charger Usage Optional Optional Lamp 1 Insert the battery into the battery charger as shown above. 2 Connect the DC JACK to the Battery Charger. 3 Plug the power cord into the electrical outlet. Connect the car charger to the printer.

  • Page 11: Belt Clip Usage

    4-7. Belt Clip Usage 4-8. Interface Cap Installation Insert screw into belt clip. When the Interface Cap is disconnected Using a sharp tool, insert the Cap Hook from the printer, try to orient the Cap into the hole located on the right side of Hook horizontally as shown in the image.

  • Page 12: Paper Roll Installation

    4-9. Paper Roll Installation Be cautious when handling the product while the Printer Cover is open. You may have a potential risk of injury when the Paper Cover closes. Open the Paper cover by pressing the Insert the paper roll so it unrolls from Open button.

  • Page 13: Install / Uninstall The External Paper Guides

    4-10. Install / Uninstall the External Paper Guides When installing the external paper guides, set the printer on the edge of a flat surface. Then insert the paper in the backside of the printer’s paper Uninstall the External Paper Guides slot and adjust the paper guide to fit the paper properly.

  • Page 14: Peel Mode

    4-11. Peel Mode Paper (1) Peel Mode Label Paper Engraved Line Paper (2) With a roll of stock installed, slide the Push the peeler body until you see Label Paper peeler body towards the back of the two complete triangles. Press the Feed printer.

  • Page 15: Shoulder Strap Installation (Optional)

    4-12. Shoulder Strap Installation 4-13. Diagnostic Test Optional Turn off the printer. Press and hold the feed button and power button. Insert the strap into the hook of the printer. NOTE 01 For Hex Dump mode, do steps 1-2 then press the feed button. 02 After printing ASCII pattern, the diagnostic test is complete.

  • Page 16: Peripheral Connection

    5. Peripheral Connection Self-Test Printout Sample This product can communicate with other devices via Bluetooth, Wi-Fi, or a communication cable. Upon initial installation or for troubleshooting, you can run the diagnostic test to get information about: - Firmware version, emulation, codepage, sensor settings, interface settings, etc.

  • Page 17: Interface Cable Connection

    6. Cleaning the Printer 5-3. Interface Cable Connection If the interior of the printer is dusty, printing quality can be reduced. In this case, follow the instructions below to clean the printer. NOTE 01 Make sure to turn the printer power off prior to cleaning. 02 Regarding printhead cleaning, as the printhead gets very hot during printing, turn off the printer power and wait approximately 10 minutes before cleaning.

  • Page 18: Platen Roller Cleaning

    7. Printer Specification 6-2. Platen Roller Cleaning Printing Method Direct Thermal Printing Speed 100 mm/sec 1 Clean the platen roller with a clean soft cloth moistened with isopropyl alcohol or a cleaning pen. Resolution 203 DPI 2 Turn the platen roller with your finger to clean the entire surface. Character ALPHA NUMERIC Character, Extension Character EAN-8, EAN-8(+2+5), EAN-13, EAN-13(+2+5),...

  • Page 19: Utilities

    Storage -30 ~ 65℃ Operation 10 ~ 90% Android Utility It is a utility app that prints text, barcodes, images, Humidity (Sewoo M_Utility) etc. through Bluetooth and Wi-Fi communication,  Storage 10 ~ 90% (ESC/POS) and able to printer settings.

  • Page 20: S/W

    Mac Driver in the Mac OS environment. Android Plugin This is a print service plug-in that allows you to print (Sewoo Print Service documents, images, and web pages without installing Plugin) (ESC/POS) additional apps. This is library for communication and data output Windows SDK with Mobile printer in Windows OS.
