F&F LE-03MW CT Manual page 10

7 current transformer – L2 phase, S2 terminal
8 current transformer – L2 phase, S1 terminal
9 current transformer – L1 phase, S2 terminal
10 current transformer – L1 phase, S1 terminal
20 RS-485 output (B)
21 RS-485 output (A)
23 pulse output (+)
24 pulse output (–)
Technical data
rated voltage
base current
maximum current
minimum detection current
transformers settings
voltage measurement
L-N
L-L
measurement accuracy
(IEC62052-11, IEC-62053-21)
overload
insulation
rated frequency
own power consumption
5/5, 30/5, 40/5, 50/5, 60/5,
75/5, 80/5, 100/5, 125/5, 150/5,
200/5, 250/5, 300/5, 400/5, 500/5,
600/5, 750/5, 800/5, 1000/5, 1250/5,
1500/5, 2000/5, 2500/5, 3000/5,
4000/5, 5000/5, 6000/5, 7500/5
- 10 -
3×230/400 V
100÷289 V AC
173÷500 V AC
30×Imax/10 ms
4 kV/1 min.; 6 kV/1 µs
<10 VA; <2 W
3×1.5 A
3×6 A
0.02 A
1st class
50 Hz
