SC1000 Series Vision Sensor Quick Start Guide
Parameter Name
Output Rising Delay
Output Falling Time
Output Rising Time
When the external voltage and resistor are different, the parameters of output logic level low
are shown below.

8.2 I/O Wiring

This section introduces how to wire the I/O parts.

8.2.1 Input Signal Wiring

Note
Input signal wiring may differ by external device types.
PNP Device
The pull-up resistor is connected to the device. A 1 KΩ pull-up resistor is recommended.
Note
Do not use a pull-up resistor more than 1 KΩ.
TDR
TF
TR
Table 8-3 Parameters of Output Logic Level Low
External Voltage
3.3 V
5 V
12 V
24 V
Symbol
4.4 µ s
116 ns
3.8 us
VL
180 mV
260 mV
500 mV
900 mV
19
Value
