Chapter 3 Appearance - HikRobot SC1000 Series Quick Start Manual

Note
Appearance here is for reference only. Refer to the device's datasheet for detailed dimension
information.
4 5
3 1 2
No. Name
1 Image Sensor
2 Light Source
3 Aiming System
4 PWR Indicator
SC1000 Series Vision Sensor Quick Start Guide

Chapter 3 Appearance

6
7
Figure 3-1 Appearance
Table 3-1 Component Description
It is used to acquire images.
It is the LED light source, which is used to provide light when
the device acquires images.
It is cross laser (device with 0.8 MP) or orange LED light
(device with 0.3 MP) used to show the field of view and aim
targets.
It is the power indicator. The indicator is green when the device
Description
6
8
