SC1000 Series Vision Sensor Quick Start Guide
Read the following section to get pin definitions of 6-pin connector.
No.
Signal
1
IO_IN
2
IO_OUT
RS232_TX
3
RS232_RX
4
5
GND
VCC
6
Note
You should refer to the table above and the label attached to the supplied power and I/O
cable to wire the device.
Chapter 4 6-Pin Connector
Figure 4-1 6-Pin Connector
Table 4-1 Pin Definitions
I/O Signal Source
LineIn1
LineOut1
-
-
-
-
Description
Non-isolated input
Non-isolated output
RS-232 serial port
output
RS-232 serial port
input
Power supply ground
Direct current power
supply positive
8
Cable Color
Blue
Gray
Yellow
White
Black
Red
