SC1000 Series Vision Sensor Quick Start Guide
Chapter 5 Device Installation and Wiring
5.1 Installation Preparation
You need to prepare following accessories before installation. The included accessories are
in the device's package, and you can purchase optional accessories according to actual
demands.
No.
Name
1
SR Cable
2
Power Adapter
3
Network Cable
5.2 Install and Wire Device
Before You Start
● Make sure the device in the package is in good condition and all the assembly parts are
included.
● Make sure that all the related devices are powered off during the installation.
Steps
1. Use the supplied screws to fix the device to the installation location.
2. Use the supplied 6-pin connector and RJ45F interface to wire the device.
● 6-pin connector: Connect the device to a power adapter or switch power supply via 6-pin
cable.
● RJ45F interface: Connect the device to a switch or NIC via network cable.
Note
If external device needs to be connected, it can be wired via the other pins of the 6-pin
connector.
Table 5-1 Accessories
Quantity
It refers to the supplied SR cable including 6-
1
pin connector to provide power and digital I/O,
and RJ45F interface to provide Ethernet.
You can select suitable power adapter or
switch power supply according to the device
1
power supply and consumption. You need to
purchase separately.
It refers to the category 5 cable (Cat 5) or
1
above. You need to purchase separately.
9
Description
