Vision sensor

Advertisement

No.
Name
5
OK/NG Indicator
6
Button
7
SR Cable
8
Screw Hole
SC1000 Series Vision Sensor Quick Start Guide
operates normally. Otherwise, it is red.
It indicates the result of solution.
● The green indicator lights when the solution result is OK.
● The red indicator lights when the solution result is NG.
● When switching solutions, the indicators both light.
Note
The indicators may differ by device models. Please refer to the
actual one.
It is used to trigger device. When the device is in trigger mode,
press the button and the device triggers once.
SR cable includes 6-pin connector and RJ45F interface to
provide power, digital I/O, Ethernet, and serial port.
It is used to fix the device to installation position. You should
use M3 screw.
Description
7
