Chapter 5 Device Installation and Wiring
5.1 Installation Preparation
You need to prepare following accessories before installation. The included accessories are
in the device's package, and you can purchase optional accessories according to actual
demands.
No.
Name
1
Power and I/O Cable
2
M12 Network Cable
3
Installation Bracket
4
Lens Cap
5
Light Board
No.
Name
1
Power Adapter
SC3000X Series Vision Sensor Quick Start Guide
Table 5-1 Included Accessories
1
1
1
1
1
Table 5-2 Optional Accessories
Quantity
It refers to the 3-meter 12-pin M12 to open
cable.
It refers to the 3-meter M12 to RJ45 network
cable.
It is used to fix the device.
The device has a polarized + diffused + full-
transparent lens cap by default.
Note
It can be replaced with other lens cap
according to actual demands.
The device has a light board integrating white
point light source × 4 and white diffused light
source × 18 by default.
Note
It can be replaced with red/blue/IR light board.
Quantity
You should select suitable power adapter or
1
switch power supply according to the device
power supply and consumption.
10
Description
Description
