IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE
HOMEOWNER
FOR YOUR SAFETY
WARNING: If the information in this manual
is not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.
-- Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
-- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fi re department.
-- Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
This appliance may be installed in
an aftermarket permanently located,
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases, unless a certifi ed kit is
used.
270606-40
DIRECT VENT FIREPLACE
INSTALLATION
AND OPERATING
INSTRUCTIONS
ESTATE_HM
SERIES H
ESTH.BODYAM
5055.8.B1
Advertisement
Table of Contents
Related Manuals for Pacific energy The Estate H Series
Summary of Contents for Pacific energy The Estate H Series
- Page 1 IMPORTANT: THESE INSTRUCTIONS ARE TO REMAIN WITH THE HOMEOWNER FOR YOUR SAFETY WARNING: If the information in this manual is not followed exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. -- Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
CONTENTS CAUTION ....................... 3 MASSACHUSETTS RULES AND REGULATIONS ..........4 REQUIREMENTS ....................5 CHASE INSULATION ................... 6 FRAMING WITHOUT SCREEN DOOR ..............7 FRAMING FOR SCREEN DOOR ................8 HEARTH EXTENSION ..................8 PROPANE CONVERSION ..................9 TOP OR REAR VENT ..................13 VENT ADAPTER INSTALLATION .............. -
Page 3: Caution
CAUTION MAINTENANCE FOR YOUR SAFETY - Do not install or operate your Pacifi c Energy Caution: Turn off gas and electrical power supply and allow ample Gas Stove without fi rst reading and understanding this manual. Any time for unit to cool before servicing appliance. It is recommended installation or operational deviation from the following instructions voids that this appliance and venting should be inspected at least once a the Pacifi c Energy Gas Stove Warranty and may prove hazardous. -
Page 4: Massachusetts Rules And Regulations
Important Note for the Commonwealth of Massachusetts: From Massachusetts Rules and Regulations 248 CMR 5.08: For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above fi... -
Page 5: Requirements
INSTALLATION REQUIREMENTS Fig. # 3 MANTEL CLEARANCES The Estate Fireplace installation and venting must conform WITH MANTEL SHIELD to the current CAN/CGA-B149 installation code (in Canada) or the National Fuel Gas Code, ANSI Z223.1 -1988 (in the USA), and approved per local codes. Only qualifi ed (licensed or trained) personnel should install this product. -
Page 6: Chase Insulation
Fig. # 3a MANTEL CLEARANCES WITH OPTIONAL SCREEN FRONT FINISHED WALL COMBUSTIBLE TOP OR MANTEL REAR VENTING EXTENDED 8" HIGH STANDOFF CEMENT BOARD MANDATORY WITH HEADER SCREEN DOORS Ref. Mantel Width Ref. Clearance Clearance Top Edge of Screen Top Edge of Unit 12"... -
Page 7: Framing Without Screen Door
FRAMING WITHOUT SCREEN DOOR installations, consult local building codes for specifi c requirements. In planning the installation for the Estate Fireplace, it is necessary to Ensure framing dimensions are maintained during construction. determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed. -
Page 8: Framing For Screen Door
FRAMING FOR SCREEN DOOR Fig. #7b CONCRETE BOARD DETAIL In planning the installation for the Estate Fireplace, it is necessary to determine where the unit is to be installed, and where the location of vent system and gas supply piping may be plumbed. Various installations Extended are possible, such as, into an existing wall, a corner, a built-in wall or a Top Standoffs... -
Page 9: Propane Conversion
PROPANE CONVERSION Caution: The gas supply and electrical power must be shut off If the Estate Direct Vent Fireplace is to be used on propane, convert before proceeding with the conversion. as follows using the components supplied with this fi replace: Items Needed For Conversion: Burner Orifi ce Pilot Orifi ce... -
Page 10: Natural Gas
8) Remove fi xed air shutter by removing screw. Reassemble with adjustable 4) Remove the brick panels if installed. air shutter only. (Fig. #11) 5) Remove the two screws holding the burner bracket in place. (Fig. #9) Fig. # 9 Fig. - Page 11 3) Remove the minimum rate screw from the bottom of the valve Fig. # 13 Hex Key and replace with the propane one supplied. (Fig. #15) Fig. # 15 Valve Conversion 1) Remove gas the supply line to the burner. 2) Remove the two wing nuts securing the burner tray to the fi replace and remove from the fi replace.
- Page 12 6) Loosen the pressure tapping screw on the valve and attach a manometer. Note the pressure tapping screw cannot be removed. (Fig.#17) The rear pressure tapping can be used to measure manifold pressure, the front pressure tapping can be used to measure supply pressure. Fig.
-
Page 13: Top Or Rear Vent
Fig. # 20a TOP OR REAR VENT Black Sealant Caution: The vent outlet not being used for venting must be blocked with the vent cover plate and gasket. Vent Adapter The Estate is capable of top or rear vent applications. The fi replace is factory set for top vent application (see Fig. -
Page 14: Venting
MATERIAL BE CLOSER THAN 1 INCH FROM THE VERTICAL selected. AND HORIZONTAL SECTIONS OF THE PACIFIC ENERGY VENT Use only Pacifi c Energy vent kits #: SYSTEM OR 1-3/4 INCHES FROM THE SIMPSON DURA-VENT GASC.WALKIT - Wall Termination Kit... -
Page 15: Roof Termination Venting And Vent Restrictor
PACIFIC ENERGY ROOF TERMINATION VENTING AND VENT RESTRICTOR Included with the unit is a Vent Restrictor. This item is used for air NOTE: The vent must be a minimum 4' long and must not exceed fl ow regulation when the vent height is 25 ft. or more. Installation of a total length of 40'. -
Page 16: Vent Connection
VENT CONNECTION Fig. # 22 Note: This section refers only to Pacifi c Energy fl ex vent. Attaching the venting to the unit before framing begins is preferred. Once the fi replace is in position proceed to attach the venting. (see Fig # 21) The fl exible vent pipe may be stretched to accommodate various lengths of venting. -
Page 17: Vent Extension
VENT EXTENSION Fig. # 24 Note: This section refers only to Pacifi c Energy fl ex vent. PIPE SUPPORT Vent Pipe Kits may be combined together for longer vent length. Extend the fl ex pipes as shown in fi gure # 24. Use the 4 and 8 inch couplers supplied with the vent kit. -
Page 18: Vent Terminal Installation
VENT TERMINAL INSTALLATION Fig. # 26 Where a vent pipe passes through a combustible wall, a wall thimble must be used to retain insulation and maintain a 1 inch clearance. The wall thimble may be cut to length for various wall thicknesses. (see Fig. -
Page 19: Roof Vent Terminal Installation
ROOF VENT TERMINAL INSTALLATION Fig. # 28 Firestops must be used where a vent passes through a fl oor. Where a vent passes through a ceiling, a wall/roof thimble must be used to retain 10 1/2" insulation and maintain a 1 inch clearance. Avoid cutting rafters. 1) Once the terminal location is determined, cut and frame a minimum 10-1/2"... -
Page 20: Roof Vent Terminal
Fig. # 29 Fig. # 30 6) Place the storm collar down over the pipe until it is level. Tighten roof vent terminal. Secure to the collar with screws provided. Seal the storm collar for a snug fi t. Apply a thick horizontal ring of mastic around joint and screw heads using the high temperature sealant provided. -
Page 21: Optional Venting
OPTIONAL VENTING SIMPSON DURA-VENT - DIRECT VENT GS SYSTEM The Estate Fireplace is also tested and certifi ed for use with SIMPSON Follow the vent pipe manufacturer's instructions for assembly and DURA-VENT DIRECT VENT GS pipe. Kits for venting either through installation. - Page 22 Fig. # 31c ROOF TERMINATION ROOF TERMINATION TOP VENTING REAR VENTING MAX. DURA-VENT GS DURA-VENT GS N OT E : T h e r o o f HORIZONTAL RUN termination vent must not exceed a total length of 40 feet. Any combination of rise and run may be used but must be constrained to the boundaries of this...
- Page 23 Fig. # 31e Venting System Components Dura-Vent GS Catalog # galv. black 6" pipe length 908B 9" pipe length 907B 12" pipe length 906B 24" pipe length 904B 36" pipe length 903B 48" pipe length 902B 11" - 14 5/8" adjustable pipe length 911B 90°...
-
Page 24: Optional Snorkel Vent Terminal
TERMINATION 36" CAP - # 981 14" CAP - # 982 PACIFIC ENERGY FLEX VENT * Minimum distance from the fi nished fl oor to the center of the opening varies with top or rear venting and vent system used. -
Page 25: Manufactured (Mobile) Home
MANUFACTURED (MOBILE) HOME Correct gas pressure requirement: In some jurisdictions, the Estate Fireplace may be installed in Manufactured Homes after the "fi rst sale". Consult local codes for Natural Gas Propane approval. The fi replace must be fastened in place. Min. -
Page 26: Burner Removal
BURNER REMOVAL Fig. # 33 Caution: Turn off gas and electrical power supply and allow ample time for the unit to cool before proceeding. The glass frame must be removed, if installed, to remove the burner from the fi rebox. The glass frame is held in place by three over-center latches located under the fi rebox along the front edge. -
Page 27: Log Set Assembly
LOG SET ASSEMBLY Fig. # 36 Step 1 Unpack and inspect log set. There should be a total of 7 logs, one Ember Floor Pt# 5097.26105 ember bed and two base brick panels. Gas and vent connections should be completed before installing the log set. Position the logs, ember bed and base bricks as indicated by pictures below. - Page 28 Fig. # 38a Fig. #37 Step 5 Middle Front Log Pt# 5097.23 Step 7 Right Front Chunk Pt# 5097.2614 Step 6 Left Front Log Pt# 5097.25 Step 8 Left Front Chunk Pt# 5097.2613 Fig. # 38b Complete Log Set Placement ESTATE_HM 270606-44...
-
Page 29: Optional Blower
OPTIONAL BLOWER 115 VOLTS Fig. # 40 60 Hz Electrical Supply: 0.5 AMPERES It is recommended that the fi replace electrical receptacle box be prewired during installation The optional blower (kit # ESTG.BLOWA) ROCKER SNAP DISC SWITCH SWITCH is equipped with a three prong power cord and may be installed and plugged in at a later date. -
Page 30: Screen Door Installation
SCREEN DOOR INSTALLATION Slide the spring nuts (supplied) over the slotted holes in the outer WARNING: Non-combustible facing material and extended top stand- frame, one in each corner (see Fig. #41). offs must be used if the Optional Screen Door is to be installed. Position the Screen Door in place and fasten to the outer frame Do not install the Optional Screen Door onto an Estate Fireplace that with the #8 x 1/2"... -
Page 31: First Fire
LIGHTING INSTRUCTIONS FIRST FIRE Extend Shutdown: When lit for the fi rst time, the appliance will emit a slight odour for To shutdown the appliance including the pilot, partially a couple of hours. This is due to the curing of paints, sealants and depress and turn gas valve knob clockwise past “PILOT”... -
Page 32: Remote Operation
REMOTE OPERATION e) Press the "timer" button for the fourth and fi nal time, the "P2 (moon)" appears, set the time you wish the fi replace to go off in the evening The Broadway Direct Vent Insert comes equipped with a thermostatic using the large "up"... -
Page 33: Replacement Parts
REPLACEMENT PARTS Fig. # 44 (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. 1....BURNER ASSEMBLY ........BRNA.3770 12 ....LOUVER, BOTTOM ASSEMBLY ....ESTD.1721_ _ 2....PANEL, RIGHT OR LEFT SIDE .......5098.403 13 ....FRONT FACING FRAME ......ESTD.1714 3....PANEL, BACK ..........5098.402 14 ....OPTIONAL BLOWER KIT ....... -
Page 34: Burner Replacement Parts
BURNER REPLACEMENT PARTS (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. 1....BURNER MOUNTING BRACKET .......2811.02 10 ....SCREW, #8x1/2" (20 required) ........5041 2....VALVE BRACKET ............3730 11 ....WING NUT, 1/4-20 (2 required) ......5049.3 3....GRATE REAR STANDOFF ........3761 12 ....GASKET, HEAT EXCHANGER ..... -
Page 35: Louver Installation Guide
APPENDIX A Louver Installation Guide Metalic Black ESTD.BKLVR Gold ESTD.GDLVRA Nickel ESTD.NILVRA This kit contains: 1..Top Louver 1..Bottom Louver 2..#8 x 1/2" sheet metal screws Installation Unpack and inspect all parts. A fl athead or a #2 Robertson screwdriver is required Fig. -
Page 36: Wall Termination Kit
Wall Termination Kit GASC.WALKIT This vent kit is for use with these models: The ESTATE and The ESTEEM fi replaces. Please refer to the Installation Instructions provided with the appliance for proper venting installation. This box contains: 1 ..Horizontal Vent Terminal 4 .. -
Page 37: Roof Termination Kit
Roof Termination Kit ESTD.ROTKIT This vent kit is for use with these models: The ESTATE and The ESTEEM fi replaces. Please refer to the Installation Instructions provided with the appliance for proper venting installation. This box contains: 1 ..Roof Vent Terminal 3 .. -
Page 38: 5' Vent Pipe Kit
5' Vent Pipe Kit ESTD.VP05 This vent kit is for use with these models: The ESTATE and The ESTEEM fi replaces. Please refer to the Installation Instructions provided with the appliance for proper venting installation. This box contains: 5' ..4" Flex Vent 3 .. -
Page 39: 10' Vent Pipe Kit
10' Vent Pipe Kit ESTD.VP10 This vent kit is for use with these models: The ESTATE and The ESTEEM fi replaces. Please refer to the Installation Instructions provided with the appliance for proper venting installation. This box contains: 1 ....Firestop 10' .... -
Page 40: Safety Label
Safety Label Pacifi c Energy Fireplace Products Ltd. Duncan, British Columbia, Canada Certifi ed for / Certifi é pour Canada and U.S.A. MADE IN CANADA This Appliance is Equipped For Use With / FABRIQUE AU CANADA Cet Appareil est Équipé Pour Utilise Avec : MODEL/ SERIES/ NATURAL GAS... - Page 41 NOTES 270606-44 ESTATE_HM...
- Page 42 NOTES ESTATE_HM 270606-44...
- Page 43 NOTES 270606-44 ESTATE_HM...
- Page 44 Pacifi c Energy Fireplace Products Ltd. 1-877-715-2664 Technical Support: www.pacifi cenergy.net 2975 Allenby Rd., Duncan, B.C. V9L 6V8 Printed in Canada ESTATE_HM 270606-44...
