IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE
HOMEOWNER
FOR YOUR SAFETY
WARNING:
If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
-- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
--Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
This appliance may be installed in an
aftermarket
permanently
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases, unless a certified kit is
used.
220803-40
ESTEEM_B
located,
AND OPERATING
The
Esteem
SERIES B
DIRECT VENT FIREPLACE
INSTALLATION
INSTRUCTIONS
5056.411.B
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pacific energy B Series

  • Page 1 IMPORTANT: THESE INSTRUCTIONS ARE TO REMAIN WITH THE HOMEOWNER FOR YOUR SAFETY WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
  • Page 2: Table Of Contents

    Contents CAUTION ......................3 SAFETY ......................3 MAINTENANCE ....................3 TOP STANDOFFS ....................5 INSTALLATION REQUIREMENTS ..............6 FRAMING ......................6 FRAMING FOR SCREEN FRONT ..............7 TOP OR REAR VENT ..................8 VENT ADAPTER INSTALLATION ..............8 VENTING ......................9 VENT SYSTEM RESTRICTOR ADJUSTMENT ..........
  • Page 3: Caution

    CAUTION MAINTENANCE FOR YOUR SAFETY - Do not install or operate your Pacific Energy Caution: Turn off gas and electrical power supply and allow ample fireplace without first reading and understanding this manual. Any time for unit to cool before servicing appliance. It is recommended...
  • Page 4 Mantel to appliance ..See Figure # 3 and 3a Maximum mantel extension..See Figure # 3 and 3a Mantel support ....0 in. (0 mm) Pacific Energy Vent pipe ..1 in. (25 mm) Simpson Dura-Vent GS pipe ....1-3/4 in. (45 mm) Security Chimneys Secure Vent pipe ..
  • Page 5: Top Standoffs

    MANTEL CLEARANCES Fig. # 3c WITH OPTIONAL SCREEN FRONT FINISHED WALL COMBUSTIBLE MANTEL TOP OR REAR VENTING 1" [25mm.] STANDOFF HEADER 8" HIGH CEMENT BOARD MANDATORY WITH SCREEN DOORS Ref. Mantel Width Ref. Clearance Clearance Top Edge of Screen Top Edge of Unit 4"...
  • Page 6: Installation Requirements

    3/8 inch thick, if thicker, fireplace must be spaced up accordingly. Fig. # 6 CORNER FRAMING FRAMING DIMENSIONS Fig. # 5 DIMENSIONS 12" * Pacific Energy Flex Pipe requires 5 1/4" ESTEEM_B 220803-40...
  • Page 7: Framing For Screen Front

    FRAMING FOR SCREEN FRONT Fig. #6b CONCRETE BOARD DETAIL In planning the installation for the Esteem Fireplace, it is necessary to determine where the unit is to be installed, location of vent system and where gas supply piping may be plumbed. Various installations are Extended possible, such as, into an existing wall, a corner, a built-in wall or a wall Top Standoffs...
  • Page 8: Top Or Rear Vent

    Secure in place with screws previously removed (see Fig. #10). VENT ADAPTER INSTALLATION The Esteem fireplace easily adapts to use either the Pacific Energy Flex Vent, Simpson Dura-Vent GS or Security Secure Vent venting system. Each system requires a specific vent adapter. Pacific Flex Vent adapter (ENCD.PEADPT) or Dura-Vent / Secure Vent adapter...
  • Page 9: Venting

    Cover Plate CAUTION: UNDER NO CONDITION SHOULD COMBUSTIBLE MATERIAL BE CLOSER THAN 1 INCH FROM THE VERTICAL AND HORIZONTAL SECTIONS OF THE PACIFIC ENERGY FLEX VENT SYSTEM AND 1-3/4 INCHES FROM THE SIMPSON DURA- VENT GS and SECURITY SECURE VENT SYSTEM.
  • Page 10 45° elbow, reduce vent length by 1 foot. 4’ 3’ 5’ 2’ 4’ 1’ 3’ 24" 2’ 1’ 24" 26 1/8" A = 39 1/2" - Pacific Energy Flex Vent = 36 3/4" - Simpson Dura-Vent GS - Security Secure Vent ESTEEM_B 220803-40...
  • Page 11 Fig. # 14 ROOF TERMINATION 40’ MAX. VENTING CHART NOTE: The vent must not exceed a total length of 40 feet. combination of rise and run may be used but must be constrained to the boundaries of this chart. For 35’...
  • Page 12: Vent System Restrictor Adjustment

    VENT SYSTEM RESTRICTOR ADJUSTMENT Fig. # 15c Located on the firebox rear wall are vent restrictors. The unit leaves the factory with the restrictors wide open as shown in Fig. 15b. These are built into the appliance for combustion air flow rate adjustment. WALL AND ROOF Adjustment of these restrictors ensures proper flame appearance for TERMINATION...
  • Page 13: Flex Vent Connection

    FLEX VENT CONNECTION Fig. # 17 It is preferred to attach venting before framing begins. Once the fireplace is in position proceed to attach the venting (see Fig #16). The flexible vent pipe may be stretched to accommodate various lengths of venting. Stretch and/or cut to length as required. The 4 inch flexible inner pipe must be centred inside the 8 inch pipe with pipe spacers provided.
  • Page 14: Vent Extension

    Top Vent: Pacific Energy Flex Vent - 39 1/2" Simpson Dura-Vent GS - 36 3/4" Security Secure Vent - 36 3/4" Rear Vent: All vent systems - 26 1/8"...
  • Page 15: Vent Terminal Installation

    VENT TERMINAL INSTALLATION Fig. # 21 Where a vent pipe passes through a combustible wall, a wall thimble must be used to retain insulation and maintain a 1 inch clearance. The wall thimble may be cut to length for various wall thicknesses (see Fig. #18).
  • Page 16: Roof Vent Terminal Installation

    ROOF VENT TERMINAL INSTALLATION Fig. # 23 Firestops must be used where a vent passes through a floor. Where a vent passes through a ceiling, a wall/roof thimble must be used to 10 1/2" retain insulation and maintain a 1 inch clearance. Avoid cutting rafters.
  • Page 17 Fig. # 24 Fig. # 26 6) Place the storm collar down over the pipe until it is level. Tighten vent terminal. Secure to the collar with screws provided. Seal the joint storm collar for a snug fit. Apply a thick horizontal ring of mastic and screw heads using the high temperature sealant provided.
  • Page 18: Optional Venting

    (see Fig. #11 and 12). For longer horizontal runs, the the side wall or vertically through the roof are available from the vent manufacturer or your nearest Pacific Energy Authorized Dealer. vertical rise must increase. The rise and run must be constrained to the boundaries of the chart shown in figure #13.
  • Page 19: Optional Snorkel Vent Terminal

    * Minimum distance from the finished floor to the center of the opening varies with top or rear venting and vent system used. Top Vent: Pacific Energy Flex Vent - 39 1/2" Simpson Dura-Vent GS - 36 3/4" Security Secure Vent - 36 3/4"...
  • Page 20: Manufactured (Mobile) Home

    MANUFACTURED (MOBILE) HOME Correct gas pressure requirement: In some jurisdictions, the Esteem Fireplace may be installed in Manufactured Homes after the "first sale". Consult local codes for Natural Gas Propane approval. The fireplace must be fastened in place. Install in accordance with the current standard Mobile Homes, CAN/ Min.
  • Page 21: Burner Removal

    BURNER REMOVAL Fig. # 31 Caution: Turn off gas and electrical power supply and allow ample time for the unit to cool before proceeding. The glass frame must be removed, if installed, to remove the burner from the firebox. The glass frame is held in place by two over-center latches located under the firebox.
  • Page 22: Ember Material

    Fig. # 32 Ember Material Placement (Andiron removed for clarity) FRONT PLATINUM GLOWING COAL BRIGHT EMBERS EMBERS EMBER MATERIAL Platinum Bright Embers adjacent to burner ports, creating a channel as shown in figure above. Place Glowing Embers randomly on the burner area and away from burner ports.
  • Page 23: Log Set Assembly

    LOG SET ASSEMBLY Fig. # 33 Step 3 Right Rear Log Placement (log #4) Unpack and inspect log set. There should be a total of 5 logs plus one coal. Gas and vent connections should be completed before install- ing the log set. All logs are numbered on the underside, for their order of assembly.
  • Page 24: Optional Blower

    OPTIONAL BLOWER 115 VOLTS Fig. # 37 60 Hz Electrical Supply: 0.5 AMPERES It is recommended that the fireplace electrical receptacle box be ROCKER SNAP DISC prewired during installation The optional blower (kit # ENCD.BLOW) SWITCH SWITCH is equipped with a three prong power cord and may be installed and plugged in at a later date.
  • Page 25: Screen Door Installation

    SCREEN DOOR INSTALLATION WARNING: Non-combustible facing material and extended top Unpack and inspect the Screen Door. A flathead or a #2 Robertson standoffs must be used if the Optional Screen Door is to be installed. screwdriver is required to install this kit. The Screen Door must be installed before the top and bottom louvers.
  • Page 26: Lighting Instructions

    LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING phone in your building. WARNING: If you do not follow these - Immediately call your gas supplier from a neigh- instructions exactly, a fire or explosion bour's phone. Follow the gas supplier's instruc- may result causing property damage, tions.
  • Page 27: First Fire

    FIRST FIRE FLAME ADJUSTMENT When lit for the first time, the appliance will emit a slight odour for a The air shutter on the burner venturi tube controls the primary couple of hours. This is due to the curing of paints, sealants and combustion air to the gas burner.
  • Page 28: Replacement Parts

    ....FRONT RIGHT, #6 (not shown) ....... 5097.26 All parts may be ordered from your nearest Pacific Energy Gas Stove dealer. Contact Pacific Energy for the location of the dealer nearest you. When ordering Overlays and Louvers, please specify the appropriate finish code. Codes are as follows: Porcelain Finish Black .........
  • Page 29: Burner Replacement Parts

    ....EMBERS, BRIGHT PLATINUM (not shown) ..5096.98 10 ..IGNITER BRACKET ..........5016.6 ....EMBERS, GLOWING (not shown) ..EMBR.506862 All parts may be ordered from your nearest Pacific Energy Gas Stove dealer. Contact Pacific Energy for the location of the dealer nearest you.
  • Page 30 APPENDIX A Louver Kit Installation Guide The ESTEEM METALLIC BLACK ENCD.LVMBK BRASS FINISH ENCD.LVBRA PORCELAIN BLACK ENCD.LVPBK Tools: PORCELAIN BLUE ENCD.LVPBE PORCELAIN GREEN ENCD.LVPGN (screwdrivers) PORCELAIN IVORY ENCD.LVPIY PORCELAIN RED ENCD.LVPRD #2 Robertson OR #2 Phillips PORCELAIN GRAPHITE ENCD.LVPGT This kit contains: 1 ..Top Louver 1 ..Bottom Louver 2 ..#8 x 1/2"...
  • Page 31: Optional Front Facing Trim

    Optional Front Facing Trim Esteem Installation Guide This kit contains: 1 ..Top Panel 1 ..Left Side Panel 1 ..Right Side Panel 6 ..#8 x 1/2" sheet metal screws (black in colour) 9 ..Fibre washers 1 ..Bottom Trim Bar Porcelain Enamel finish only 6 ..
  • Page 32 Installation Spring nut Fig. # 1 Unpack and inspect all parts. A flathead or a #2 Robertson screwdriver is required to install this kit. The facing trim kit must be installed before the top and bottom louvers. If the louvers are not installed, proceed to step 3.
  • Page 33 Optional Blower Kit ESTEEM ENCD.BLOW This kit contains: 1 ..Blower assembly 1 ..Speed Control box pre-wired with: -Power cord -Thermo-switch -Manual / Auto switch Blower Assembly Power Cord Speed Control Box 2 ..#8 x 1/2" Sheet metal screws (black in colour) Installation: Please see instruction manual.
  • Page 34: Wall Termination Kit

    Wall Termination Kit GASC.WALKIT This vent kit is for use with model The ESTATE and The ESTEEM fireplaces. Please refer to the Installation Instructions provided with the appliance for proper venting installation. This box contains: 1 ..Horizontal Vent Terminal 4 ..
  • Page 35: 5' Vent Pipe Kit

    5' Vent Pipe Kit ESTD.VP05 This vent kit is for use with model The ESTATE and The ESTEEM fireplaces only. Please refer to the Installation Instructions provided with the appliance for proper venting installation. This box contains: 5' ..4" Flex Vent 3 ..
  • Page 36: 10' Vent Pipe Kit

    10' Vent Pipe Kit ESTD.VP10 This vent kit is for use with the model ESTATE and ESTEEM fireplaces only. Please refer to the Installation Instructions provided with the appliance for proper venting installation. This box contains: 10' ... 4" Flex Vent 1 ....
  • Page 37: Roof Termination Kit

    Roof Termination Kit ESTD.ROTKIT This vent kit is for use with model The ESTATE and The ESTEEM fireplaces. Please refer to the Installation Instructions provided with the appliance for proper venting installation. This box contains: 1 ..Roof Vent Terminal 3 ..
  • Page 38 - notes - ESTEEM_B 220803-40...
  • Page 39: Safety Label

    Mantel Supports / Supports du manteau 0 in./ 0 po. (0 mm) Pacific Energy Flex Pipe system / le système Conduit Flexible de Pacific Energy 1 in./ 1 po. (25 mm) Dura-Vent GS or Secure Vent system / le système Dura-Vent GS ou Secure Vent 1 3/4 in./ 1 3/4 po.
  • Page 40 Pacific Energy Fireplace Products Ltd. PO Box 1060, Duncan, B.C. V9L 3Y2 Phone: 250-748-1184 Web site: http://www.pacificenergy.net Printed in Canada ESTEEM_B 220803-40...
