Removing the Steering Servo Motor
Before you can remove the steering servo motor, you must open the steering servo housing (Opening the
Steering Servo Housing, page 76).
1 Support the top of the steering servo housing on the edge of a bench or a table and not on the top of the
shaft carrier when removing the steering servo motor.
NOTICE
Do not clamp the top of the housing to the bench or table to support it. Clamping the housing may damage the
coating or bend the housing.
2 Using a #2 Phillips screwdriver, remove the clip that secures the motor cable to the housing.
