Garmin FORCE Field Service Manual page 10

Checking and Replacing the Mount Rails
The rails protect the propeller drive motor and the mount from impact when stowing the motor, and may
become worn over time. If the rails are damaged or worn and the mount base is visible through them, you must
replace them.
1 With the motor in the stowed position, examine the rails
2 Select an action:
• If the rails are in good condition, and you cannot see the metal mount base though any worn areas, no
further action is needed.
• If the rails are damaged or if you can see the metal mount base through worn areas in the rails, proceed to
the next step to replace them.
3 Using a 4 mm hex bit or wrench, remove the screws
4 Slide the damaged rails off of the mount base.
5 Slide the replacement rails onto the mount base.
6 Secure the shrouds to the mount base using the screws you removed previously.
10
for wear and damage.
that secure the shrouds to the mount base.
