JLG Telehandler 360 Installation Guide
This guide will show the proper way to install a 360 Camera system in a JLG Telehandler. Please review
the Installation Guidelines for grounding and making connections prior to installing. In this guide you will
find dash removal, wire locations, & mounting locations.
After testing and verifying power wires, disconnect the negative battery terminal to prevent any
Verify no vehicle service lights are on prior to installation. Contact a Fleet Manager immediately if the
For Technical Support please contact our support team at:
Gray – Caution
Red – Warning
Version 2.10.2
accidental shorts or blown fuses
vehicle has any damage
Techsupport@Roscovision.com
Blue – Extra Installation Parts Needed
Purple – New Installation
Proprietary and Confidential
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Rosco SAFE-T-SCOPE 360
Summary of Contents for Rosco SAFE-T-SCOPE 360
- Page 1 JLG Telehandler 360 Installation Guide This guide will show the proper way to install a 360 Camera system in a JLG Telehandler. Please review the Installation Guidelines for grounding and making connections prior to installing. In this guide you will find dash removal, wire locations, &...
- Page 2 JLG Telehandler 360 Installation Guide Before starting your installation please take note of component mounting locations. Version 2.10.2 Proprietary and Confidential...
-
Page 3: Step 1 - Power Connections
JLG Telehandler 360 Installation Guide Make sure the battery kill switch is turned off before connecting power. The switch is located under the hood of the vehicle Step 1 - Power Connections: • The Fuse Panel is located on the left side of the lower dash •... - Page 4 JLG Telehandler 360 Installation Guide Power Connections (Continued): • Crimp ring terminals to the constant, ignition, and ground wires • Connect the YELLOW CONSTANT wire to the 1 terminal labeled B+ • Connect the RED IGNITION wire to the 2 terminal labeled IGN •...
- Page 5 JLG Telehandler 360 Installation Guide Step 2 - ECU MOUNTING: • Mount the ECU on the support brace to the right of the fuse panel • Make sure you mount the ECU with the Calibration Port facing the rear of the vehicle •...
- Page 6 JLG Telehandler 360 Installation Guide Camera Mounting Locations: Version 2.10.2 Proprietary and Confidential...
- Page 7 JLG Telehandler 360 Installation Guide Use extreme caution when routing video cables. Take note of all pinch points when routing cables outside of the vehicle. Its best to lift the boom to see where all moving parts are. Always use wire loom when running wires outside.
- Page 8 JLG Telehandler 360 Installation Guide Rear Camera Cable Routing: • Follow factory routed hydraulic lines when routing rear camera cables (Photo A) • Keep cables away from all moving parts. Carefully lift the boom to find the safest route (Photo •...
- Page 9 JLG Telehandler 360 Installation Guide Left & Right Camera Cable Routing (Continued): • With the Left camera mounted on the roof, enter the vehicle from the grommet • Run the cables in the headliner and down the side pillar to the door sill (Photo A) •...
- Page 10 JLG Telehandler 360 Installation Guide Front Camera Cable Routing: • Route the front camera cable inside the tubing that holds the headlight (Photo A) • After exiting the tube, follow the factory cabling inside the battery box (Photo B) • Remove the four (4) 13MM bolts securing the battery box cover (Photo B) •...
- Page 11 JLG Telehandler 360 Installation Guide 360 User view after calibration Version 2.10.2 Proprietary and Confidential...
