1 - Right sidewall
1 pc.
5 - Middle wall
1 pc.
3
Pic. 1
Take the front and middle walls (3, 5) and using wooden dowels (b)
attach the shelves (6). Then attach front and back walls (4, 5) to
the shelves (6) using confirmat screws (a) and hex key (c). See Pic. 1.
Floor bookcase "Cloud"
ASSEMBLY DETAILS
2 - Left sidewall
1 pc.
6 - Shelf
2 pcs.
5
b
3 - Front wall
1 pc.
a - Confirmat screw
5x40
10 pcs.
4 - Back wall
1 pc.
b - Wooden dowel
6x30
10 pcs.
4
6
a
6
c - 3 mm hex key
1 pc.
Advertisement
Related Manuals for Montessori Furniture Cloud
Summary of Contents for Montessori Furniture Cloud
- Page 1 Floor bookcase "Cloud" ASSEMBLY DETAILS 1 - Right sidewall 2 - Left sidewall 3 - Front wall 4 - Back wall 1 pc. 1 pc. 1 pc. 1 pc. 5 - Middle wall 6 - Shelf a - Confirmat screw...
- Page 2 Pic. 2 Attach the sidewalls (1, 2) to the previously assebled construction using wooden dowels (b) and fix the parts with confirmat screws (a) using hex key (c). See Pic. 2. Use only for its intended purpose, indoors, under the direct supervision of adults.
