DEVICE DESCRIPTION: The SHOUT nano 100 relays Global Navigation Satellite System (GNSS) / Global Positioning

System (GPS) location data and other critical data.

POWER ON DEVICE

Hold down the Power/Enter button for two (2) seconds

and release it. The Main screen appears.

MESSAGING

The Messaging function allows you to view incoming messages,

send canned messages and erase messages.

CONFIGURATION

The Configuration function allows you to enable tracking, set track report rate, set the check mailbox rate,

Contrast, Back Light and Reset Settings.

Select Configuration>Enable Tracking.

Select Enable.

Select Configuration>Trk Rep Rate.

Select (scroll) for the desired track report rate.

IMPORTANT:

SHOUT nano 100 must have a clear view of the sky during transmission.

NOTE: For additional detailed information, refer to the SHOUT nano 100 user guide.

SHOUT nano 100 QUICK START GUIDE

Support Phone#: 703-392-1136

Support@Nalresearch.com

451-22013-002A

7/15/2024

Need help?

Do you have a question about the SHOUT nano 100 and is the answer not in the manual?

Page 1 Support Phone#: 703-392-1136 Support@Nalresearch.com 451-22013-002A 7/15/2024 DEVICE DESCRIPTION: The SHOUT nano 100 relays Global Navigation Satellite System (GNSS) / Global Positioning System (GPS) location data and other critical data. POWER ON DEVICE Hold down the Power/Enter button for two (2) seconds and release it.
Page 2 The BT Pairing function enables the device to be discovered and paired with another device. IMPORTANT: SHOUT nano 100 must have a clear view of the sky during transmission. NOTE: For additional detailed information, refer to the SHOUT nano 100 user guide.
Page 3 Charge with the supplied AC wall adapter AC Wall Adapter USB-A to USB-C Cable IMPORTANT: SHOUT nano 100 must have a clear view of the sky during transmission. NOTE: For additional detailed information, refer to the SHOUT nano 100 user guide.
